Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 400, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SILEX LITE, material: aluminium, 700x38C / 650Bx45C max.WHS, 100x12/142x12mm axle standard, BB86 bottom bracket standard, MUK 36/ MUK 41 (Shimano direct mount) Hanger
Suspension Fork
MERIDA SILEX CF2, Tapered, material: carbon, 700x38C / 650Bx45C max. wheelsize
Drivetrain
Rear Derailleur
Shimano GRX400
Front Derailleur
Shimano GRX400
Shift Levers
Shimano GRX400
Cassette
Shimano CS-HG50, 11-36 teeth, 10 speed
Crank
Shimano GRX600, 46-30 teeth, 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
Bottom Bracket
Shimano Pressfit BB71
Chain
KMC X10
Wheels
Front Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 32 spoke holes, centerlock, 142x12mm width rear hub, 32 spoke holes, centerlock
Rear Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 32 spoke holes, centerlock, 142x12mm width rear hub, 32 spoke holes, centerlock
Rims
MERIDA COMP SL, 17mm inner width, 22mm height, material: aluminium
Spokes
Black stainless
Tires
Maxxis Rambler, 700x38C, fold, TR, EXO
Brakes
Brakes
Shimano GRX400, Hydraulic disc
Brake Levers
Shimano GRX400
Disk Rotors
Shimano RT10, 160 mm
Cockpit
Stem
MERIDA EXPERT CW, material: aluminium, 31.8mm diameter, -8° stem angle, 80 mm all sizes
Handlebar
MERIDA EXPERT GR, material: aluminium, 400mm (XS-S), 420mm (M), 440mm (L/XL)
Headset
MERIDA M2331
Seat
Saddle
MERIDA COMP SL, V-mount
Seatpost
MERIDA COMP CC, material: aluminium, 30.9mm diameter, 0mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.56 mm | 1.55 mm | 1.54 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 615 mm | 641 mm | 663 mm | 684 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm |
| Stack | 608 mm | 627 mm | 646 mm | 665 mm |
| Reach | 382 mm | 402 mm | 417 mm | 432 mm |
| Top Tube Length | 556 mm | 581 mm | 602 mm | 622 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1036 mm | 1062 mm | 1084 mm | 1105 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 746 mm | 774 mm | 801 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
SILEX 400 is a Merida Silex model. Merida launched 43 bikes of this model so far. You can easily view all of the Merida Silex bikes models from 2022, here.
Model range prices
Merida SILEX 300 2022 is the most affordable bike of this model and has a price of 1273$. On the other hand, Merida SILEX 4000 2022, is the most expensive and costs 2615$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1946$. Comparing the average cost of a Gravel bike to this one, you will see that SILEX 400 price is 26.52% smaller.
SILEX 400 components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the SILEX 400 model has 700c aluminum wheels. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SILEX 400 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Merida SILEX 400 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
