Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SILEX LITE, material: aluminium, 700x38C / 650Bx45C max.WHS, 100x12/142x12mm axle standard, BB86 bottom bracket standard, MUK 36/ MUK 41 (Shimano direct mount) Hanger
Suspension Fork
MERIDA SILEX CF2, Tapered, material: carbon, 700x38C / 650Bx45C max. wheelsize
Drivetrain
Rear Derailleur
Shimano GRX810
Front Derailleur
Shimano GRX810
Shift Levers
Shimano GRX810
Cassette
Shimano CS-HG700, 11-34 teeth, 11 speed
Crank
Shimano GRX810, 48-31 teeth, 170 mm-XS/S, 172,5 mm-M, 175 mm-L/XL
Bottom Bracket
Shimano Pressfit BB71
Chain
KMC X11
Wheels
Front Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 32 spoke holes, centerlock, 142x12mm width rear hub, 32 spoke holes, centerlock
Rear Hub
VP CLK170F / VP CLK270R, 100x12mm width front hub, 32 spoke holes, centerlock, 142x12mm width rear hub, 32 spoke holes, centerlock
Rims
MERIDA EXPERT CX, 19mm inner width, 24mm height, material: aluminium
Spokes
Double Butted Black stainless
Tires
Maxxis Rambler, 700x38C, fold, TR, EXO
Brakes
Brakes
Shimano GRX810, Hydraulic disc
Brake Levers
Shimano GRX810
Disk Rotors
Shimano RT64, 160mm
Cockpit
Stem
MERIDA EXPERT CW, material: aluminium, 31.8mm diameter, -8° stem angle, 80 mm all sizes
Handlebar
MERIDA EXPERT GR, material: aluminium, 400mm (XS-S), 420mm (M), 440mm (L/XL)
Headset
MERIDA M2331
Seat
Saddle
MERIDA COMP SL, V-mount, incl. MERIDA minitool
Seatpost
MERIDA EXPERT CC, material: carbon, 30.9mm diameter, 0mm setback
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.59 mm | 1.55 mm | 1.54 mm | 1.53 mm |
| Bottom Bracket Height | 274 mm | 274 mm | 274 mm | 274 mm | 274 mm |
| Front Center | 608 mm | 615 mm | 641 mm | 663 mm | 684 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Stack | 593 mm | 612 mm | 631 mm | 650 | 669 mm |
| Reach | 386 mm | 386 mm | 406 mm | 421 mm | 436 mm |
| Top Tube Length | 554 mm | 560 mm | 585 mm | 606 mm | 626 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 160 mm | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1033 mm | 1040 mm | 1066 mm | 1088 mm | 1109 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 722 mm | 750 mm | 778 mm | 805 mm | 832 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
SILEX 700 completes the Merida Silex model. 43 bikes variations carry this model name so far. You can easily view all of the Merida Silex bikes models from 2022, here.
Model range prices
Merida SILEX 300 2022 is the cheapest bike model and costs 1273$. Merida SILEX 4000 2022 is the most expensive one and costs 2615$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2022 and its price was 2615$. Doing a quick comparison, we notice that SILEX 700 price is 6.21% more expensive than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the SILEX 700 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Merida SILEX 700 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
