Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RockShox 35 Silver
-
Groupset SX Eagle, FSA -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Power Tube 625 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kore- G2. AC Frame. Aluminum 6061 Hydroformed Double butted. TA 12mm. Internal Cable Routing. Boost. PostMount. Full Integrated battery. Ebike Optimized. Head Tube Tapered 1.5
Suspension Fork
Rock Shox 35 Silver Air Crown 15 Boost. E-bike. Travel 100mm. Tapered
Drivetrain
Rear Derailleur
SRAM SX 12V
Cassette
XCR 11-50
Crank
FSA Forged E-bike 34
Chain
YBN 12V
Wheels
Rims
Shimano MT-500 CL HG
Tires
Hutchinson Griffus TLR Sideskin 29x2.50
Brakes
Brakes
Shimano MT-200 180/160
Cockpit
Stem
Ritchey Trail
Handlebar
Ritchey Comp 2x720mm
Headset
Ritchey Pro Press Fit Tapered 1.5
Seat
Saddle
San Marco GND Dynamic
Seatpost
Ritchey Comp Zero 30.9
Motor & Battery
Motor
Bosch Performance Line CX
Battery
Bosch Power Tube 625
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.53 mm | 1.49 mm | 1.46 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 694 mm | 718 mm | 737 mm | 756 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 95 mm | 95 mm | 95 mm | 95 mm |
| Stack | 629 mm | 639 mm | 647 mm | 657 mm |
| Reach | 399 mm | 419 mm | 434 mm | 449 mm |
| Top Tube Length | 581 mm | 604 mm | 621 mm | 639 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 394 mm | 432 mm | 483 mm | 533 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 464 mm | 464 mm | 464 mm | 464 mm |
| Wheelbase | 1152 mm | 1176 mm | 1195 mm | 1214 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Koen 10 belongs to the Mmr E Koen model. There are 2 e-bikes that carry this model name. Take a sneak peek at all Mmr E Koen e-bikes models from 2023, by clicking here.
Model range prices
MMR Koen 10 2023 is the cheapest e-bike model and costs 3917$. MMR Koen 00 2023 is the most expensive one and costs 4552$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry e-bikes average price
If you want an acceptable Crosscountry e-bike you should know that the average price is 2453$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, MMR Koen 10 price was 3917$. Comparing the average cost of a Crosscountry e-bike to this one, you will see that Koen 10 price is 59.68% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Koen 10 components
Fork
The RockShox 35 Silver is included from the factory. It has a travel distance of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, MMR Koen 10 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
When you want to stop the bike in time, the brakes are vital. The Koen 10 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Koen 10 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
