Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Lyrik Select
-
Groupset XT, FSA -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Power Tube 625 -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Bolt - G2 Carbon Concept Frame. Intermediate modulus carbon fiber. Several moulds. TA 12mm. Internal Cable Routing. Boost. PostMount. Full Integrated Battery. Head tube 1.5 Tapered
Suspension Fork
RockShox Lyric Select 35 Air Crown E-Bike 29 140mm
Rear Shock
RockShox Super Deluxe Select, E-Bike 140
Drivetrain
Rear Derailleur
Shimano XT M8100 SGS 12V
Cassette
Shimano Deore M6100 10/51 12V
Crank
FSA Alloy Forged 34T
Chain
Shimano Deore M6100 12V
Wheels
Rims
XCR-9800 Hybrid MT400 / MT510B Boost CL MS
Tires
Hutchinson Griffus 29 2.50 TL SideSkin
Brakes
Brakes
SRAM DB8 200/180
Cockpit
Stem
Race Face Ride 35
Handlebar
Race Face Next R35 800mm
Seat
Saddle
San Marco GND Dynamic
Seatpost
Race Face Affect R 125mm
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
Bosch Power Tube 625
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.449 mm | 1.398 mm | 1.354 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 736 mm | 767 mm | 798 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 106 mm | 106 mm | 106 mm |
| Stack | 616 mm | 629 mm | 643 mm |
| Reach | 425 mm | 450 mm | 475 mm |
| Top Tube Length | 590 mm | 618 mm | 647 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 110 mm | 125 mm | 140 mm |
| Chainstay Length | 457 mm | 457 mm | 457 mm |
| Wheelbase | 1191 mm | 1222 mm | 1253 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
X-Bolt 140 50 belongs to the Mmr E X Bolt model. 26 e-bikes variations carry this model name so far. You can easily view all of the Mmr E X Bolt e-bikes models from 2024, here.
Model range prices
The most economical model, the MMR X-Bolt 140 70 2024 has a starting price of 5929$. MMR X-Bolt 140 10 2024 on the other hand is the most expensive at 7835$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail e-bikes average price
According to our calculations, the average cost of a Trail e-bike that is reliable is 3365$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
This e-bike was released in 2024 and its price was 6670$. Comparing the average cost of a Trail e-bike to this one, you will see that X-Bolt 140 50 price is 98.22% higher.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The X-Bolt 140 50 comes factory-installed with the RockShox Lyrik Select fork. This has a travel range of 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
As for the rear shock, this e-bike has the RockShox Super Deluxe Select model, with a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The X-Bolt 140 50 2024 e-bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. MMR X-Bolt 140 50 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
MMR X-Bolt 140 50 e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
