Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
X-Grip - G1 AC Concept Frame. Aluminum 6061. Hydroformed. Triple Butted. TA 12mm. Optimized Cable Routing. Flat Mount. Headtube 1.5mm
Suspension Fork
X-Grip - G1 Carbon Concept Fork. TA 12mm
Drivetrain
Rear Derailleur
Shimano GRX RX820 12V
Cassette
Shimano 105 R7100 11/36T 12V
Crank
Shimano GRX RX610 46/30T 12V
Chain
Shimano Deore M6100 12V
Wheels
Rims
Shimano RS-171 DB CL HG
Tires
Hutchinson Touareg 40mm
Brakes
Brakes
Shimano GRX RX610 160mm
Cockpit
Stem
Ritchey Switch Comp
Handlebar
Ritchey Butane Comp
Seat
Saddle
Selle Italia X3 Boost Flow
Seatpost
Ritchey Logic
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.474 mm | 1.507 mm | 1.53 mm | 1.571 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 578 mm | 587 mm | 605 mm | 627 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 74 mm | 68 mm | 68 mm | 68 mm |
| Stack | 538 mm | 565 mm | 589 mm | 622 mm |
| Reach | 365 mm | 375 mm | 385 mm | 396 mm |
| Top Tube Length | 519 mm | 542 mm | 565 mm | 586 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 600 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 135 mm | 160 mm | 195 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 998 mm | 1007 mm | 1025 mm | 1047 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
X-Grip 10 is part of the Mmr X Grip model. 6 bikes variations carry this model name so far. You can easily view all of the Mmr X Grip bikes models from 2024, here.
Model range prices
MMR X-Grip 10 2024 is the most economical model, with a starting price of 2223$. MMR X-Grip 00 2024 on the other hand costs 2329$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
According to our math, the average price for a trustworthy Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2024 for 2223$. If we compare this with the average Gravel bike cost we notice that the price is 10.75% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
X-Grip 10 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The X-Grip 10 2024 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
X-Grip 10 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
