Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM
-
Groupset Acera, FSA -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Charger Alloy XC Frame W/Formed Tubing
Suspension Fork
Suntour XCM 29" 100mm w/Hydraulic lock-out
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera RD-M390 - Black
Front Derailleur
Shimano Acera FD-M390
Shift Levers
Jagwire
Cassette
Shimano CS-HG20 11-34T 9speed
Crank
FSA Dyna Drive 44/32/22T - Black
Bottom Bracket
FSA BB-7420ST Cartridge
Chain
SRAM PG951 9spd
Chain Tensioner
N/A
Pedals
Wellgo Resin Pedals
Wheels
Front Hub
Shimano HB-RM35 CenterLock Disc
Rear Hub
Shimano FH-RM35 CenterLock Disc
Rims
WTB SX19 29" 32H DW
Tires
Geax AKA 2.2
Brakes
Brakes
Shimano BR-M375 Mech Disc 160mm
Brake Levers
Tektro Alloy
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Alloy 15mm Riser
Grips
T-One H2O Grips
Headset
FSA No. 10 w/16mm conical spacer
Seat
Saddle
Norco XC Forma Saddle
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - |
|---|---|---|---|
| Stack Reach Ratio | 1.71 mm | 1.68 mm | 1.59 mm |
| Bottom Bracket Height | 302 mm | 302 mm | 307 mm |
| Front Center | 620 mm | 629 mm | 650 |
| Rake | 46 mm | 46 mm | 47 mm |
| Trail | 87 mm | 84 mm | 83 mm |
| Stack | 622 mm | 629 mm | 629 mm |
| Reach | 363 mm | 375 mm | 395 mm |
| Top Tube Length | 548 mm | 568 mm | 588 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 381 mm | 432 mm | 470 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1054 mm | 1063 mm | 1086 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 63 mm |
| Front Travel | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" |
Model Overview
Charger 9.3 Forma belongs to the Norco Charger model. 83 bikes variations carry this model name so far. You can easily view all of the Norco Charger bikes models from 2013, here.
Model range prices
Norco Charger 6.3 Forma 2013 is the most affordable bike of this model and has a price of 690$. On the other hand, Norco Charger 9.1 2013, is the most expensive and costs 1045$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Charger 9.3 Forma price was 724$. Comparing this to the average Crosscountry bike price, we see that the price is 163.12% smaller.
Charger 9.3 Forma components
Fork
The fork installed on this bike is the SunTour XCM model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the Charger 9.3 Forma model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
