Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork Fox Float 32
-
Groupset XT, SLX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Faze 29er aluminum 100 mm travel frame
Suspension Fork
Fox 32 Float Evolution 29 CTD O/C 100 mm 15 mm
Rear Shock
Fox Float CTD Evolution
Drivetrain
Rear Derailleur
Shimano XT RD 10 speed RD
Front Derailleur
Shimano SLX 10 speed front derailleur
Shift Levers
Jagwire LEX housing
Cassette
Shimano Deore 10 speed cassette
Crank
Shimano FC M552 2 pc 10 speed 42/32/22T
Bottom Bracket
N/A
Chain
SRAM PC 1031 10 speed
Chain Tensioner
N/A
Pedals
Wellgo alloy body / alloy cage MTB pedal
Wheels
Front Hub
Formula Front disc hub ( 15 mm)
Rear Hub
Formula DC 30 rear disc sealed bearing qr
Rims
Alex MD-17 29er rim
Tires
Schwalbe Smart Sam 29 x 2.1 tire folding bead
Brakes
Brakes
Shimano SLX hydraulic brake w/ 160 mm rotor
Brake Levers
N/A
Disk Rotors
N/A
Cockpit
Stem
Alloy 3D forged MTB stem 4 bolt front clamp
Handlebar
Norco 15 mm rise 680-720 mm width 6061 bar
Grips
T-One Single side lock on grip
Headset
FSA # 10 headset internal 50 OD / 44 ID
Seat
Saddle
Norco MTB XC Trail saddle
Seatpost
Norco Lite 3D forged double bolt 2014 alloy 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.407 mm | 1.357 mm | 1.304 mm |
| Bottom Bracket Height | 327.5 mm | 327.5 mm | 327.5 mm | 327.5 mm |
| Front Center | 667 mm | 690 mm | 703 mm | 727 mm |
| Rake | 51 mm | 51 mm | 46 mm | 46 mm |
| Trail | 82 mm | 82 mm | 84 mm | 84 mm |
| Stack | 598 mm | 605 mm | 612 mm | 618 mm |
| Reach | 409 mm | 430 mm | 451 mm | 474 mm |
| Top Tube Length | 575 mm | 598 mm | 621 mm | 645 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 107 mm | 110 mm | 117 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1108 mm | 1132 mm | 1144 mm | 1169 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 789 mm | 774 mm | 781 mm | 793 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Faze 9.1 is part of the Norco Faze model. Norco launched 22 bikes of this model so far. Check out the entire range from 2014 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Faze 9.3 2014 has a starting price of 1315$. Norco Faze 9.1 2014 on the other hand is the most expensive at 2330$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2014 and its price was 2330$. If we compare this with the average Crosscountry bike cost we notice that the price is 22.31% higher.
Overview of components
Fork
This bike has the Fox Float 32 fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the Fox Float CTD Evolution model, with a travel of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels
As for the wheels, Norco Faze 9.1 2014, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Faze 9.1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Faze 9.1 comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
