Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork SunTour XCR
-
Groupset Deore, Alivio -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Faze 29er aluminum 100 mm travel frame
Suspension Fork
SR Suntour XCR LO 29 100 mm hydraulic speed lockout rebound adjust
Rear Shock
X Fusion O2 R air shock with rebound adjust
Drivetrain
Rear Derailleur
Shimano Deore 9 speed Shadow type
Front Derailleur
Shimano Alivio FD
Shift Levers
Jagwire LEX housing
Cassette
Shimano CS HG 20 9 speed
Crank
Shimano Acera Octalink 9 speed 44/32/22T
Bottom Bracket
Shimano Octalink
Chain
SRAM PC 950 9 speed
Chain Tensioner
N/A
Pedals
Wellgo alloy body / steel cage MTB pedal
Wheels
Front Hub
SRAM MTH 306 front quick release disc hub
Rear Hub
SRAM MTH 306 rear disc 135 x 10 w/ QR axle
Rims
Alex MD-17 29er rim
Tires
Schwalbe Smart Sam 29 x 2.1 tire
Brakes
Brakes
Shimano BRM-395 hydraulic disc brake w/ 160 mm rotor
Brake Levers
N/A
Disk Rotors
N/A
Cockpit
Stem
Norco light alloy MTB stem 75 mm on SM 90 mm med 105mm on LG/XL
Handlebar
Norco 15 mm rise 680-720 mm width 6061 bar
Grips
Norco MTB gator design trail grip
Headset
FSA # 10 headset internal 50 OD / 44 ID
Seat
Saddle
Norco MTB XC Trail saddle
Seatpost
Norco 6061 alloy double bolt head 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.407 mm | 1.357 mm | 1.304 mm |
| Bottom Bracket Height | 327.5 mm | 327.5 mm | 327.5 mm | 327.5 mm |
| Front Center | 667 mm | 690 mm | 703 mm | 727 mm |
| Rake | 51 mm | 51 mm | 46 mm | 46 mm |
| Trail | 82 mm | 82 mm | 84 mm | 84 mm |
| Stack | 598 mm | 605 mm | 612 mm | 618 mm |
| Reach | 409 mm | 430 mm | 451 mm | 474 mm |
| Top Tube Length | 575 mm | 598 mm | 621 mm | 645 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 107 mm | 110 mm | 117 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1108 mm | 1132 mm | 1144 mm | 1169 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 789 mm | 774 mm | 781 mm | 793 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Faze 9.3 belongs to the Norco Faze model. Norco launched 22 bikes of this model so far. You can easily view all of the Norco Faze bikes models from 2014, here.
Model range prices
Norco Faze 9.3 2014 is the most economical model, with a starting price of 1315$. Norco Faze 9.1 2014 on the other hand costs 2330$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Faze 9.3 price was 1315$. Doing a quick comparison, we notice that Faze 9.3 price is 44.87% lower than the average cost of a Crosscountry bike.
Faze 9.3 components
Fork
The SunTour XCR is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is X Fusion O2 R air shock with rebound adjust, with a travel distance of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The Faze 9.3 2014 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Faze 9.3 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Norco Faze 9.3 bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
