Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 80mm -
Fork SunTour XCM
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid+ 24" Aluminum Frame"
Suspension Fork
SR Suntour XCM24+ 80mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus 8-spd - Black
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano 8-spd 11-34 Cassette
Crank
Narrow-wide 28T 3-pc Crankset - Black
Bottom Bracket
Sealed bearing square taper, 73mm - Black
Pedals
VP Alloy Flat Jr. BMX
Wheels
Front Hub
Alloy disc w/QR 110mm
Rear Hub
Alloy disc 135x10 MTB hub w/ ball bearing
Rims
Alloy 20" 35mm inner - Black"
Tires
Chaoyang MTB - 24" x 2.6"
Brakes
Brakes
Tektro Hydraulic Disc Brake, 160mm rotor - Black
Brake Levers
Tektro Jr. MTB w/ Reach adjust - Black
Cockpit
Stem
Norco Alloy 35mm - Black
Handlebar
Norco Jr. Bar 660mm, 15mm rise - Black
Grips
Norco Jr. Grip - Black
Seat
Saddle
Norco Jr. MTB Saddle 24" - Black
Seatpost
Norco Alloy 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.72 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 559 mm |
| Rake | 40 mm |
| Stack | 558 mm |
| Reach | 325 mm |
| Top Tube Length | 505 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 390 mm |
| Wheelbase | 944 mm |
| Bottom Bracket Drop | 47 mm |
| Standover Height | 700 |
| Front Travel | 80 mm |
| Wheels | 24" |
About this model
Fluid 4.3+ belongs to the Norco Fluid model. Norco launched 60 frames of this model so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
The most economical model, the Norco Fluid 2.3+ 2017 has a starting price of 519$. Norco Fluid 4.3+ 2017 on the other hand is the most expensive at 599$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Mountain frames
According to our math, the average price for a trustworthy Mountain frame is 514$. However, this doesn’t mean that if you spend less money on a Mountain frame, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
When Norco released this model in 2017, its price was 599$. If we compare this with the average Mountain frame cost we notice that the price is 16.54% more expensive.
Fluid 4.3+ components
Fork
Norco Fluid 4.3+ 2017 frame is equipped with the SunTour XCM fork, and has 80mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid 4.3+ is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
