Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset XT, Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid 27.5 aluminum 120 mm travel frame with tapered steer tube
Suspension Fork
32 Float Evolution 27.5 CTD O/C 120 mm travel 15mm tapered steer tube
Rear Shock
Fox Float CTD Evolution
Drivetrain
Rear Derailleur
Shimano XT Shadow 10 speed
Front Derailleur
Shimano Deore downswing high clamp
Shift Levers
Jagwire LEX housing
Cassette
Shimano CS HG 62 10 speed
Crank
Shimano Deore Hollow Tech II 10 speed 40/30/22T
Bottom Bracket
N/A
Chain
SRAM PC 1031 10 speed chain
Chain Tensioner
N/A
Pedals
Wellgo alloy body / steel cage MTB pedal
Wheels
Front Hub
Formula DC 51 disc hub w/15 mm axle
Rear Hub
Formula DC 32 rear disc sealed bearing Q/R
Rims
WTB Speed Disc I 23 single eyelet 27.5
Tires
Continental X-King 27.5 x 2.4 folding bead
Brakes
Brakes
Shimano Deore BRM 615 w/ 160 mm rotor
Brake Levers
Shimano Deore
Disk Rotors
N/A
Cockpit
Stem
Norco alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 25.4 mm rise 740 mm width bar
Grips
T-One lock on grip
Headset
FSA #57B ( tapered internal ) 1.5" to 1-1/8"""
Seat
Saddle
Norco MTB trail saddle
Seatpost
Norco 6061 alloy double bolt head 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 13.535 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 655 mm | 678 mm | 700 | 723 mm | 746 mm |
| Rake | 42 mm | 41 mm | -1887 mm | 42 mm | 42 mm |
| Trail | 95 mm | 96 mm | 2168 mm | 95 mm | 95 mm |
| Stack | 567 mm | 574 mm | mm | 588 mm | 595 mm |
| Reach | 389 mm | 409 mm | 429 mm | 449 mm | 469 mm |
| Top Tube Length | 547 mm | 569 mm | 591 mm | 613 mm | 635 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 100 mm | 107 mm | 115 mm | 122 mm | 130 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1076 mm | 1098 mm | 1122 mm | 1145 mm | 1167 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 18 mm | 18 mm |
| Standover Height | 746 mm | 732 mm | 764 mm | 757 mm | 749 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fluid 7.1 completes the Norco Fluid model. Norco launched 60 bikes of this model so far. You can easily view all of the Norco Fluid bikes models from 2014, here.
Model range prices
Norco Fluid 7.2 2014 is the cheapest bike model and costs 1709$. Norco Fluid 7.1 2014 is the most expensive one and costs 2275$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2014 for 2275$. If we compare this with the average Trail bike cost we notice that the price is 21.41% lower.
Overview of components
Rear Shock
As for the rear shock, this bike has the Fox Float CTD Evolution model, with a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Norco Fluid 7.1 2014, has a 27.5″ aluminum model. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid 7.1 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Norco Fluid 7.1 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
