Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Recon Silver RL
-
Groupset NX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid HT Plus 6061 Alloy Frame w/DB TT and DT
Suspension Fork
Rock Shox Recon RL Silver Solo Air 120mm/15mm
Rear Shock
Angular Sealed Cartridge Bearings - Tapered
Drivetrain
Rear Derailleur
SRAM NX 11spd
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM NX PG 1130 11/42
Crank
Alloy Boost 28T Cranks
Bottom Bracket
External Threaded BB
Chain
SRAM PC-1110 11spd
Chain Tensioner
N/A
Pedals
VP Nylon Flat Pedal
Wheels
Front Hub
Joytech Boost 110mm x 15mm
Rear Hub
Joytech Boost 141 RR QR 32H
Rims
Alex MD35 650B/26 Plus 32H
Tires
WTB Ranger 27.5"/26""x 2.8"""
Brakes
Brakes
SRAM Level T 180mm
Brake Levers
SRAM Level T
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy 60mm
Handlebar
N/A
Grips
N/A
Headset
Norco Grip
Seat
Saddle
Norco XC Saddle
Seatpost
TranzX 125mm Dropper Post 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.49 mm | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 316 mm | 316 mm | 316 mm |
| Front Center | 655 mm | 681 mm | 716 mm | 742 mm | 768 mm |
| Rake | 42 mm | 43 mm | 51 mm | 51 mm | 51 mm |
| Trail | 102 mm | 101 mm | 92 mm | 92 mm | 92 mm |
| Stack | 595 mm | 595 mm | 608 mm | 617 mm | 627 mm |
| Reach | 375 mm | 400 mm | 422 mm | 444 mm | 466 mm |
| Top Tube Length | 552 mm | 582 mm | 612 mm | 642 mm | 672 mm |
| Seat Tube Angle | 73.5 ° | 73.1 ° | 72.7 ° | 72.3 ° | 71.9 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 110 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 417 mm | 417 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1069 mm | 1095 mm | 1139 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 41 mm | 41 mm | 45 mm | 45 mm | 45 mm |
| Standover Height | 715 mm | 713 mm | 770 mm | 781 mm | 792 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fluid 7.2/6.2 HT+ is a Norco Fluid Ht model. 78 bikes variations carry this model name so far. Take a sneak peek at all Norco Fluid Ht bikes models from 2017, by clicking here.
Model range prices
Norco Fluid 7.3/6.3 HT+ 2017 is the most affordable bike of this model and has a price of 899$. On the other hand, Norco Fluid 7.1/6.1 HT+ 2017, is the most expensive and costs 1699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Norco released this model in 2017, its price was 1249$. Comparing this to the average Trail bike price, we see that the price is 121.14% lower.
Overview of components
Fork
The fork installed on this bike is the RockShox Recon Silver RL model. The travel on this model is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
As for the wheels, Norco Fluid 7.2/6.2 HT+ 2017, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid 7.2/6.2 HT+ has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
