Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Select
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
146cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
MD
172cm - 181cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Trail, 120mm Travel, 27.5" and 29" Options
Suspension Fork
RockShox Pike Select, 130mm Travel, 46mm Offset (27.5), 51mm Offset (29)
Rear Shock
RockShox Deluxe Select, 190x42.5mm (27.5), 190x45mm (29)
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX SL-M7100-IR I-Spec EV
Cassette
Shimano SLX, 10-51, 12 Speed
Crank
Shimano FC-M610, 30T, 170mm (XXS - S), 175mm (M - XL)
Bottom Bracket
Shimano Cartridge Bearing, BSA Threaded
Chain
Shimano Deore
Pedals
VP Nylon Flat
Wheels
Front Hub
Shimano HB-MT400-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stan's Flow D 32H
Tires
Maxxis Dissector 2.4" 3C/EXO/TR
Brakes
Brakes
Shimano BR-MT420, 4 Piston, Organic Pads
Brake Levers
Shimano BR-M420
Disk Rotors
Shimano SMRT54 180mm
Cockpit
Stem
6061 Alloy, 50mm Length, 35mm Clamp
Handlebar
TranzX 6061 Butted Alloy, 780mm, 20mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Fizik Taiga
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (s), 150mm (M), 170mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.4 mm | 1.33 mm | 1.37 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 671 mm | 705 mm | 739 mm | 742 mm | 777 mm | 810 mm |
| Rake | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 114 mm | 114 mm | 114 mm | 109 mm | 109 mm | 109 mm |
| Stack | 572 mm | 581 mm | 591 mm | 607 mm | 616 mm | 625 mm |
| Reach | 384 mm | 414 mm | 444 mm | 444 mm | 474 mm | 504 mm |
| Top Tube Length | 526 mm | 558 mm | 590 mm | 594 mm | 627 mm | 659 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1105 mm | 1139 mm | 1173 mm | 1173 mm | 1208 mm | 1241 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 644 mm | 658 mm | 668 mm | 686 mm | 698 mm | 708 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 146 cm | 154 cm | 163 cm | 172 cm | 172 cm | 181 cm |
| Rider Max Height | 157 cm | 166 cm | 174 cm | 181 cm | 184 cm | 191 cm |
Model Overview
Fluid FS 1 27.5 belongs to the Norco Fluid Fs model. Norco launched 111 bikes of this model so far. You can easily view all of the Norco Fluid Fs bikes models from 2021, here.
Model range prices
Norco Fluid FS 3 29 2021 is the cheapest bike model and costs 2249$. Norco Fluid FS 1 27.5 2021 is the most expensive one and costs 3399$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Fluid FS 1 27.5 price was 3399$. Comparing the average cost of a Trail bike to this one, you will see that Fluid FS 1 27.5 price is 23.06% more expensive.
Overview of components
Fork
This bike has the RockShox Pike Select fork installed. The fork’s travel is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is RockShox Deluxe Select, with a travel distance of 120mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Fluid FS 1 27.5 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Fluid FS 1 27.5 comes in 6 sizes, that range from 146 cm – 191 cm (4.79 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Fluid FS 1 27.5 includes a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
