Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork X Fusion
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
146cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
MD
172cm - 181cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Trail, 120mm Travel, 27.5" and 29" Options
Suspension Fork
X-Fusion RC32 Air, 130mm Travel, 46mm Offset (27.5), 51mm Offset (29)
Rear Shock
X-Fusion 02 Pro R, 190x42.5mm (27.5), 190x45mm (29)
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle
Cassette
SRAM PG-1210 Eagle, 11-50T
Crank
SRAM SX Eagle, 30T, 170mm (XXS - S), 175mm (M - XL)
Bottom Bracket
Truvativ Powerspline BB, BSA Threaded
Chain
SRAM SX Eagle
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy 15x110mm Boost, 6 Bolt
Rear Hub
Alloy 12x148mm, HG, 6 Bolt
Rims
Stan's Flow D 32H
Tires
Goodyear Newton 2.4" Folding
Brakes
Brakes
Tektro HD-M275 Hydraulic
Brake Levers
Tektro HD-M275
Disk Rotors
Tektro 180mm
Cockpit
Stem
6061 Alloy, 50mm Length, 35mm Clamp
Handlebar
TranzX 6061 Butted Alloy, 780mm, 20mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm (S, M), 150mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.4 mm | 1.33 mm | 1.37 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 671 mm | 705 mm | 739 mm | 742 mm | 777 mm | 810 mm |
| Rake | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 114 mm | 114 mm | 114 mm | 109 mm | 109 mm | 109 mm |
| Stack | 572 mm | 581 mm | 591 mm | 607 mm | 616 mm | 625 mm |
| Reach | 384 mm | 414 mm | 444 mm | 444 mm | 474 mm | 504 mm |
| Top Tube Length | 526 mm | 558 mm | 590 mm | 594 mm | 627 mm | 659 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1105 mm | 1139 mm | 1173 mm | 1173 mm | 1208 mm | 1241 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 644 mm | 658 mm | 668 mm | 686 mm | 698 mm | 708 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 146 cm | 154 cm | 163 cm | 172 cm | 172 cm | 181 cm |
| Rider Max Height | 157 cm | 166 cm | 174 cm | 181 cm | 184 cm | 191 cm |
Model Overview
Fluid FS 3 29 is part of the Norco Fluid Fs model. 111 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Norco Fluid FS 3 29 2021 is the cheapest bike model and costs 2249$. Norco Fluid FS 1 27.5 2021 is the most expensive one and costs 3399$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2021 for 2249$. If we compare this with the average Trail bike cost we notice that the price is 22.81% smaller.
Overview of components
Fork
This bike has the X Fusion fork installed. The fork’s travel is 130mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The Fluid FS 3 29 has a rear shock with a travel of 120mm. The model X-Fusion 02 Pro R is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When it comes to wheels, the Fluid FS 3 29 bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid FS 3 29 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 6 sizes. They vary from 146 cm – 191 cm (4.79 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Fluid FS 3 29. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
