Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 75mm -
Travel Rear 83mm -
Fork RST
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid alloy 20” frame with 95 mm travel
Suspension Fork
RST First 24 60mm air w/lock, alloy steer
Rear Shock
Rockshox Monarch R
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus GS 10 spd
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano HG-50 11-36T 10 spd
Crank
Samox 2pc w/28T narrow/wide,10sp 140mm
Bottom Bracket
Square taper sealed bearing BB
Pedals
Wellgo JR one piece design
Wheels
Front Hub
Novatec alloy Q/R disc front
Rear Hub
Novatec alloy Q/R 10/11sp cass hub semi sealed
Rims
Alex DP 17 double wall 20” rim
Tires
Maxxis Maxx Daddy 20x2.0
Brakes
Brakes
Tektro Hydraulic disc brake w/shorter reach
Brake Levers
Tektro
Cockpit
Stem
Kalloy 35mm reach MTB stem 31.8
Handlebar
Norco 6061DB 640mm width 31.8 w25mm rise
Grips
MTB JR trail grip
Seat
Saddle
Norco Jr. XC trail saddle
Seatpost
Norco 6061 alloy double bolt 30.9 x 250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.46 mm |
| Front Center | 534 mm |
| Rake | 58 mm |
| Stack | 444 mm |
| Reach | 304 mm |
| Top Tube Length | 447 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 300 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 357 mm |
| Wheelbase | 889 mm |
| Bottom Bracket Drop | 25 mm |
| Standover Height | 572 mm |
| Front Travel | 75 mm |
| Rear Travel | 83 mm |
| Wheels | 20" |
Model Overview
Fluid FS 2.2 belongs to the Norco Fluid Fs model. Norco released 111 frames variations of this model so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Norco Fluid FS 2.2 2017 is the most economical model, with a starting price of 1499$. Norco Fluid FS 4.2 2017 on the other hand costs 1699$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Mountain frames
Our math shows that the average cost of a dependable Mountain frame is 514$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain frame. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2017 for 1499$. Doing a quick comparison, we notice that Fluid FS 2.2 price is 191.63% higher than the average cost of a Mountain frame.
Overview of components
Fork
Norco Fluid FS 2.2 2017 frame is equipped with the RST fork, and has 75mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this frame is made out of aluminum, so there won’t be much extra weight added to the frame. However, they are not so stiff as carbon forks are.
Rear Shock
From the factory, it comes with the Rockshox Monarch R rear shock model, which has a travel of 83mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid FS 2.2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
