Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox Recon Silver RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fluid alloy 24” frame with 100 mm travel
Suspension Fork
Rockshox Recon Silver, air spring 100mm, alloy steer
Rear Shock
Rockshox Monarch R
Drivetrain
Rear Derailleur
Shimano Deore Shadow Plus SGS 10 spd
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Shimano HG-50 11-36T 10 spd
Crank
Samox crank w/28T 152mm
Bottom Bracket
Square Taper Cartridge
Pedals
Wellgo Jr. one piece design
Wheels
Front Hub
Novatec alloy disc
Rear Hub
Novatec alloy Q/R 10/11sp cass hub semi sealed
Rims
Alex DP21 double wall I21 Tubeless ready
Tires
Maxxis Snyper 24x2.0 folding bead
Brakes
Brakes
Tektro Hydraulic disc brake w/shorter reach
Brake Levers
Tektro
Cockpit
Stem
Short reach 35mm ext MTB stem
Handlebar
Norco 6061 alloy 1” rise bar
Grips
Norco MTB gator design trail grip
Seat
Saddle
Norco Jr. XC trail saddle
Seatpost
JD TransX dropper post w/remote lever, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | N/A |
|---|---|
| Stack Reach Ratio | 1.55 mm |
| Bottom Bracket Height | 312 mm |
| Front Center | 585 mm |
| Rake | 42 mm |
| Stack | 522 mm |
| Reach | 337 mm |
| Top Tube Length | 505 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 68 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 420 mm |
| Wheelbase | 1005 mm |
| Bottom Bracket Drop | 2 mm |
| Standover Height | 675 mm |
| Front Travel | 100 mm |
| Rear Travel | 100 mm |
| Wheels | 24" |
Model Overview
Fluid FS 4.2 is part of the Norco Fluid Fs model. Norco launched 111 frames of this model so far. You can easily view all of the Norco Fluid Fs frames models from 2017, here.
Model range prices
Norco Fluid FS 2.2 2017 is the most affordable frame of this model and has a price of 1499$. On the other hand, Norco Fluid FS 4.2 2017, is the most expensive and costs 1699$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Mountain frames
If you want to purchase a solid Mountain frame, it is important to know that the average cost is 514$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Mountain frame. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Fluid FS 4.2 price was 1699$. Comparing this to the average Mountain frame price, we see that the price is 230.54% higher.
Fluid FS 4.2 components
Fork
The RockShox Recon Silver RL is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
The fork is made out of aluminum, so there won’t be much extra weight added to the frame. However, they are not so stiff as carbon forks are.
Rear Shock
From the factory, it comes with the Rockshox Monarch R rear shock model, which has a travel of 100mm. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, get a full-suspension bike if you want the smoothest rides.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid FS 4.2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Dropper post
The Norco model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
