Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Select
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
146cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Trail, 120mm Travel, 27.5" and 29" Options, UDH
Suspension Fork
RockShox Pike Select, 130mm Travel, 46mm Offset (27.5), 51mm Offset (29)
Rear Shock
RockShox Deluxe Select, 190x42.5mm (27.5), 190x45mm (29)
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX SL-M7100-IR I-Spec EV
Cassette
Shimano SLX, 10-51, 12 Speed
Crank
Shimano FC-M610, 30T, 170mm (XXS - S), 175mm (M - XL)
Bottom Bracket
Shimano Cartridge Bearing, BSA Threaded
Chain
Shimano Deore
Pedals
VP Nylon Flat
Wheels
Front Hub
Shimano HB-MT400-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stan's Flow D 32H
Tires
Maxxis Dissector 2.4" 3C/EXO/TR
Brakes
Brakes
Front: Shimano BR-MT420, 4 Piston, Organic Pads, Rear: Shimano BR-MT420, 4 Piston, Organic Pads
Brake Levers
Shimano BR-M420
Cockpit
Stem
6061 Alloy, 50mm Length, 35mm Clamp
Handlebar
TranzX 6061 Butted Alloy, 780mm, 20mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Fizik Taiga
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (s), 150mm (M), 170mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 671 mm | 705 mm | 739 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 114 mm | 114 mm | 114 mm |
| Stack | 572 mm | 581 mm | 591 mm |
| Reach | 384 mm | 414 mm | 444 mm |
| Top Tube Length | 526 mm | 558 mm | 590 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1105 mm | 1139 mm | 1173 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Standover Height | 644 mm | 658 mm | 668 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 146 cm | 154 cm | 163 cm |
| Rider Max Height | 157 cm | 166 cm | 174 cm |
About this model
Fluid FS A1 27.5 is part of the Norco Fluid Fs model. Norco released 117 bikes variations of this model so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Norco Fluid FS A3 29 2021 is the cheapest bike model and costs 2011$. Norco Fluid FS 1 27.5 2021 is the most expensive one and costs 3399$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2021, its price was 3070$. Doing a quick comparison, we notice that Fluid FS A1 27.5 price is 11.15% more expensive than the average cost of a Trail bike.
Overview of components
Fork
Norco Fluid FS A1 27.5 2021 bike is equipped with the RockShox Pike Select fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The Fluid FS A1 27.5 has a rear shock with a travel of 120mm. The model RockShox Deluxe Select is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Fluid FS A1 27.5 are the 27.5″ aluminum type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid FS A1 27.5 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Norco Fluid FS A1 27.5 bike has 3 sizes, in the range of 146 cm – 174 cm (4.79 ft – 5.71 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Norco Fluid FS A1 27.5 includes a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
