Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox Pike Select
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Trail, 120mm Travel, 27.5" and 29" Options, UDH
Suspension Fork
RockShox Pike Select, 130mm Travel, 46mm Offset (27.5), 51mm Offset (29)
Rear Shock
RockShox Deluxe Select, 190x42.5mm (27.5), 190x45mm (29)
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX SL-M7100-IR I-Spec EV
Cassette
Shimano SLX, 10-51, 12 Speed
Crank
Shimano FC-M610, 30T, 170mm (XXS - S), 175mm (M - XL)
Bottom Bracket
Shimano Cartridge Bearing, BSA Threaded
Chain
Shimano Deore
Pedals
VP Nylon Flat
Wheels
Front Hub
Shimano HB-MT400-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stan's Flow D 32H
Tires
Maxxis Dissector 2.4" 3C/EXO/TR
Brakes
Brakes
Front: Shimano BR-MT420, 4 Piston, Organic Pads, Rear: Shimano BR-MT420, 4 Piston, Organic Pads
Brake Levers
Shimano BR-M420
Cockpit
Stem
6061 Alloy, 50mm Length, 35mm Clamp
Handlebar
TranzX 6061 Butted Alloy, 780mm, 20mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Fizik Taiga
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (s), 150mm (M), 170mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 742 mm | 777 mm | 810 mm |
| Rake | 51 mm | 51 mm | 51 mm |
| Trail | 109 mm | 109 mm | 109 mm |
| Stack | 606 mm | 615 mm | 624 mm |
| Reach | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 593 mm | 626 mm | 658 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1172 mm | 1207 mm | 1240 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm |
| Standover Height | 685 mm | 697 mm | 707 mm |
| Wheels | 29" | 29" | 29" |
| Rider Min Height | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 175 cm | 184 cm | 191 cm |
Model Overview
Fluid FS A1 29 belongs to the Norco Fluid Fs model. Norco launched 117 bikes of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Norco Fluid FS A3 29 2021 is the cheapest bike model and costs 2011$. Norco Fluid FS 1 27.5 2021 is the most expensive one and costs 3399$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3070$. In conclusion, this bike price is 11.15% more expensive than the price of the average Trail bike.
Fluid FS A1 29 components
Fork
Norco Fluid FS A1 29 2021 bike is equipped with the RockShox Pike Select fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Norco Fluid FS A1 29 bike has the RockShox Deluxe Select model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Fluid FS A1 29 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid FS A1 29 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Norco Fluid FS A1 29 bike has 3 sizes, in the range of 163 cm – 191 cm (5.35 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Fluid FS A1 29 comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
