Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork X-Fusion RC32
-
Groupset SX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
146cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Trail, 120mm Travel, 27.5" and 29" Options, UDH
Suspension Fork
X-Fusion RC32 Air, 130mm Travel, 46mm Offset (27.5), 51mm Offset (29)
Rear Shock
X-Fusion 02 Pro R, 190x42.5mm (27.5), 190x45mm (29)
Drivetrain
Rear Derailleur
SRAM SX Eagle
Shift Levers
SRAM SX Eagle
Cassette
SRAM PG-1210 Eagle, 11-50T
Crank
SRAM SX Eagle, 30T, 170mm (XXS - S), 175mm (M - XL)
Bottom Bracket
Truvativ Powerspline BB, BSA Threaded
Chain
SRAM SX Eagle
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy 15x110mm Boost, 6 Bolt
Rear Hub
Alloy 12x148mm, HG, 6 Bolt
Rims
Stan's Flow D 32H
Tires
Front: Goodyear Newton 2.4" Folding, Rear: Goodyear Escape 2.35" Folding
Brakes
Brakes
Front: Tektro HD-M275 Hydraulic, Rear: Tektro HD-M275 Hydraulic
Brake Levers
Tektro HD-M275
Cockpit
Stem
6061 Alloy, 50mm Length, 35mm Clamp
Handlebar
TranzX 6061 Butted Alloy, 780mm, 20mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm (S, M), 150mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm |
| Front Center | 671 mm | 705 mm | 739 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 114 mm | 114 mm | 114 mm |
| Stack | 572 mm | 581 mm | 591 mm |
| Reach | 384 mm | 414 mm | 444 mm |
| Top Tube Length | 526 mm | 558 mm | 590 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1105 mm | 1139 mm | 1173 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm |
| Standover Height | 644 mm | 658 mm | 668 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 146 cm | 154 cm | 163 cm |
| Rider Max Height | 157 cm | 166 cm | 174 cm |
About this model
Fluid FS A3 27.5 belongs to the Norco Fluid Fs model. Norco launched 117 bikes of this model so far. Take a sneak peek at all Norco Fluid Fs bikes models from 2021, by clicking here.
Model range prices
Norco Fluid FS A3 29 2021 is the most economical model, with a starting price of 2011$. Norco Fluid FS 1 27.5 2021 on the other hand costs 3399$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2021, its price was 2011$. Doing a quick comparison, we notice that Fluid FS A3 27.5 price is 37.34% smaller than the average cost of a Trail bike.
Overview of components
Fork
This bike has the X-Fusion RC32 fork installed. The fork’s travel is 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Fluid FS A3 27.5 bike has the X-Fusion 02 Pro R model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
As for the wheels, Norco Fluid FS A3 27.5 2021, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid FS A3 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Fluid FS A3 27.5 comes in 3 sizes, that range from 146 cm – 174 cm (4.79 ft – 5.71 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
Norco Fluid FS A3 27.5 includes a dropper post. Therefore, climbing or descending will be a breeze.
