Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox Sektor
-
Groupset NX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
RockShox Sektor RL, Boost 15x110mm thru axle
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12-speed
Front Derailleur
N/A
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM NX 1230 Eagle, 10-50 tooth, 12-speed
Crank
SRAM NX Eagle, 170mm on XS/S, 175mm of M/L/XL
Bottom Bracket
SRAM DUB, threaded BSA 73mm
Chain
SRAM NX Eagle, 12-speed
Chain Guide
None
Pedals
VP Nylon Flat, 9/16"
Wheels
Front Hub
Front: Novatec Boost 110mm x 15mm, Rear: Joytech D142TSE, 9x141mm quick release
Rear Hub
Front: Novatec Boost 110mm x 15mm, Rear: Joytech D142TSE, 9x141mm quick release
Rims
Alex MD-35, 32 hole, 35mm internal width
Spokes
Stainless steel 14g, black
Tires
WTB Ranger, 2.8"
Brakes
Brakes
Front: Shimano Altus BR-M201, 180mm rotor, Rear: Shimano Altus BR-M201, 160mm rotor
Brake Levers
Shimano Altus BR-M201
Cockpit
Stem
Alloy, 60mm x 31.8mm
Handlebar
X6 Alloy, 750mm x 31.8mm
Grips
VP, Lock-on
Headset
Angular sealed cartridge bearings
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18JL Stealth dropper, 120mm (XS/S), 130mm (M/L/XL), 1x lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.49 mm | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 316 mm | 316 mm | 316 mm |
| Stack | 595 mm | 595 mm | 608 mm | 617 mm | 627 mm |
| Reach | 375 mm | 400 mm | 422 mm | 444 mm | 466 mm |
| Top Tube Length | 552 mm | 582 mm | 612 mm | 642 mm | 672 mm |
| Seat Tube Angle | 73.5 ° | 73.1 ° | 72.7 ° | 72.3 ° | 71.9 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 110 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 417 mm | 417 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1069 mm | 1095 mm | 1139 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 715 mm | 714 mm | 770 mm | 781 mm | 792 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Fluid HT 1 completes the Norco Fluid Ht model. 78 bikes variations carry this model name so far. You can easily view all of the Norco Fluid Ht bikes models from 2019, here.
Model range prices
Norco Fluid HT 4 Women 26 2019 is the cheapest bike model and costs 799$. Norco Fluid HT 1 27.5 2019 is the most expensive one and costs 1699$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2019 for 1699$. If we compare this with the average Trail bike cost we notice that the price is 62.57% smaller.
Overview of components
Fork
This bike has the RockShox Sektor fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
When it comes to wheels, the Fluid HT 1 bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid HT 1 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
