Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork Suntour XCM
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
146cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Butted TT, DT, Internal Routing, 27.5" and 29" Options
Suspension Fork
SR Suntour XCM32 LOR DS, 120mm Travel
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100
Shift Levers
Shimano Deore SL-M5100
Cassette
Shimano Deore CS-M5100, 11-51T, 11 Speed
Crank
Shimano Deore FC-M5100-1, 30T, 170mm (XS, S,), 175mm (M, L, XL)
Bottom Bracket
Shimano Sealed Bearing BSA Threaded
Chain
KMC X11
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy 15x110mm Boost, 6 Bolt
Rear Hub
Alloy 12x148mm, HG, 6 Bolt
Rims
Alex DP30 TRS
Tires
Maxxis Ardent 2.4" EXO 60TPI
Brakes
Brakes
Front: Tektro HD-M275 Hydraulic, Resin Pads, Rear: Tektro HD-M275 Hydraulic, Resin Pads
Brake Levers
Tektro HD-M275
Cockpit
Stem
Alloy 50mm Length, 31.8mm Clamp
Handlebar
X6 Alloy 750mm, 15mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.44 mm | 1.37 mm |
| Bottom Bracket Height | 320 mm | 320 mm | 320 mm |
| Front Center | 670 mm | 704 mm | 738 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 114 mm | 114 mm | 114 mm |
| Stack | 589 mm | 598 mm | 607 mm |
| Reach | 384 mm | 414 mm | 444 mm |
| Top Tube Length | 546 mm | 579 mm | 611 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1101 mm | 1135 mm | 1169 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm |
| Standover Height | 602 mm | 621 mm | 651 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 146 cm | 154 cm | 163 cm |
| Rider Max Height | 157 cm | 166 cm | 174 cm |
About this model
Fluid HT 2 27.5 is part of the Norco Fluid Ht model. There are 78 bikes that carry this model name. You can easily view all of the Norco Fluid Ht bikes models from 2023, here.
Model range prices
Norco Fluid HT 20.1+ 2023 is the most economical model, with a starting price of 599$. Norco Fluid HT 1 29 2023 on the other hand costs 1599$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1199$. Comparing this to the average Trail bike price, we see that the price is 130.36% smaller.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
Norco Fluid HT 2 27.5 2023 bike is equipped with the Suntour XCM fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The Fluid HT 2 27.5 2023 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Fluid HT 2 27.5 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 3 sizes. They vary from 146 cm – 174 cm (4.79 ft – 5.71 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Fluid HT 2 27.5 includes a dropper post. Therefore, climbing or descending will be a breeze.
