Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 24" -
Travel Front 80mm -
Fork Suntour XCR Air
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
24"
128cm - 142cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum, Internal Routing, Internal Dropper Post Compatible
Suspension Fork
SR Suntour XCR Air, Lockout, 80mm Travel, Light Tune
Drivetrain
Rear Derailleur
Shimano Altus, Black
Shift Levers
Shimano Altus SL-M315 RapidFire
Cassette
SunRace, 11-34T, 8 Speed
Crank
Alloy 3 Piece, 28T Narrow Wide, 152mm
Bottom Bracket
Sealed Bearing, Square Taper
Chain
KMC
Pedals
Jr. MTB Flat, Black
Wheels
Front Hub
Alloy, 9x100mm, 6 Bolt
Rear Hub
Alloy, 10x135mm, HG, 6 Bolt
Rims
Aluminum Double Wall, 28H, 24"
Tires
Vee Crown Gem 2.25"
Brakes
Brakes
Tektro HD-M286 Hydraulic
Brake Levers
Tektro 2-Finger Jr.
Disk Rotors
Tektro, 6-Bolt
Cockpit
Stem
Alloy, 45mm Length, 31.8mm Clamp
Handlebar
Alloy Jr., 600mm, 30mm Rise
Grips
Norco Youth
Headset
External Cup
Seat
Saddle
Norco Youth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.4 mm |
| Bottom Bracket Height | 267 mm |
| Front Center | 619 mm |
| Rake | 39 mm |
| Stack | 520 mm |
| Reach | 372 mm |
| Top Tube Length | 529 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 305 mm |
| Head Tube Angle | 66 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 387 mm |
| Wheelbase | 1002 mm |
| Bottom Bracket Drop | 43 mm |
| Wheels | 24" |
| Rider Min Height | 128 cm |
| Rider Max Height | 142 cm |
Model Overview
Fluid HT 24.1 belongs to the Norco Fluid Ht model. There are 78 bikes that carry this model name. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Norco Fluid HT 20.2 2022 is the cheapest bike model and costs 599$. Norco Fluid HT 1 27.5 2022 is the most expensive one and costs 1749$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Mountain bikes average price
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, even if your budget is less than the average, you might still be able to get a top-quality Mountain bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Fluid HT 24.1 price was 999$. In conclusion, this bike price is 62.18% higher than the price of the average Mountain bike.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork
The Suntour XCR Air is included from the factory. It has a travel distance of 80mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
The wheels on Fluid HT 24.1 are the 24″ aluminum type. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
