Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCM
-
Groupset NX, Suntour SR -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
SR Suntour XCM32, Boost 15x110mm thru axle, LOR, DS
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM NX, 11-speed
Front Derailleur
N/A
Shift Levers
SRAM NX, 11-speed
Cassette
SRAM NX PG-1130, 10-42 tooth, 11-speed
Crank
SR Suntour Zeron Boost, 170mm on XS/S, 175mm on M/L/XL
Bottom Bracket
SR Suntour BB24, threaded BSA 73mm
Chain
SRAM NX PC-1110, 11-speed
Chain Guide
None
Pedals
VP Nylon Flat, 9/16"
Wheels
Front Hub
Front: Novatec Boost 110mm x 15mm, Rear: Joytech D142TSE, 9x141mm quick release
Rear Hub
Front: Novatec Boost 110mm x 15mm, Rear: Joytech D142TSE, 9x141mm quick release
Rims
Alloy XD26, 32 hole, 30mm internal width
Spokes
Stainless steel 14g, black
Tires
WTB Ranger, 2.8"
Brakes
Brakes
Front: Tektro HD-M275, 2 piston hydraulic disc, 180mm rotor, Rear: Tektro HD-M275, 2 piston hydraulic disc, 160mm rotor
Brake Levers
Tektro HD-M275
Cockpit
Stem
Alloy, 60mm x 31.8mm
Handlebar
X6 Alloy, 750mm x 31.8mm
Grips
VP, Lock-on
Headset
Angular sealed cartridge bearings
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18JL Stealth dropper, 120mm, 1x lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.59 mm | 1.49 mm | 1.44 mm | 1.39 mm | 1.35 mm |
| Bottom Bracket Height | 311 mm | 311 mm | 316 mm | 316 mm | 316 mm |
| Stack | 595 mm | 595 mm | 608 mm | 617 mm | 627 mm |
| Reach | 375 mm | 400 mm | 422 mm | 444 mm | 466 mm |
| Top Tube Length | 552 mm | 582 mm | 612 mm | 642 mm | 672 mm |
| Seat Tube Angle | 73.5 ° | 73.1 ° | 72.7 ° | 72.3 ° | 71.9 ° |
| Seat Tube Length | 380 mm | 410 mm | 440 mm | 470 mm | 500 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 110 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 417 mm | 417 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1069 mm | 1095 mm | 1139 mm | 1165 mm | 1191 mm |
| Bottom Bracket Drop | 44 mm | 44 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 715 mm | 714 mm | 770 mm | 781 mm | 792 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Fluid HT 3 belongs to the Norco Fluid Ht model. Norco released 78 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Norco Fluid HT 4 Women 26 2019 is the most economical model, with a starting price of 799$. Norco Fluid HT 1 27.5 2019 on the other hand costs 1699$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1349$. If we compare this with the average Trail bike cost we notice that the price is 104.74% smaller.
Overview of components
Fork
This bike has the SunTour XCM fork installed. The fork’s travel is 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the Fluid HT 3 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid HT 3 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Norco Fluid HT 3 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the Fluid HT 3. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
