Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 80mm -
Fork Suntour XCM
-
Groupset Altus -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
24"
128cm - 142cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Fluid HT+ 24", Aluminum
Suspension Fork
SR Suntour XCM 24+, 80mm Travel
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Shift Levers
Shimano Altus, RevoShift
Cassette
Shimano Altus CS-HG31, 11-34T, 8 Speed
Crank
3-Piece, 152mm, Narrow-Wide 28T
Bottom Bracket
Sealed Cartridge, BSA 73mm
Chain
KMC Z7
Pedals
VP Alloy Flat Jr. BMX
Wheels
Front Hub
Alloy disc, 110mm
Rear Hub
Alloy Disc ,135x10mm
Rims
Alloy 24", 35mm Inner Width
Tires
Chaoyang MTB, 2.6"
Brakes
Brakes
Front: Tektro HD-M286, Hydraulic Disc, Rear: Tektro HD-M286, Hydraulic Disc
Brake Levers
Tektro HD-M286, Short Reach
Cockpit
Stem
Norco Alloy, 35mm Length
Handlebar
Norco Jr., 660mm, 15mm Rise
Grips
Norco Jr.
Headset
FSA No. 10P
Seat
Saddle
Norco Jr. MTB
Seatpost
Norco Alloy, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.72 mm |
| Bottom Bracket Height | 274 mm |
| Front Center | 559 mm |
| Rake | 40 mm |
| Stack | 558 mm |
| Reach | 325 mm |
| Top Tube Length | 505 mm |
| Seat Tube Angle | 72 ° |
| Seat Tube Length | 320 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 390 mm |
| Wheelbase | 944 mm |
| Bottom Bracket Drop | 47 mm |
| Standover Height | 704 mm |
| Wheels | 24" |
| Rider Min Height | 128 cm |
| Rider Max Height | 142 cm |
About this model
Fluid HT+ 4.3 is part of the Norco Fluid Ht model. There are 78 bikes that carry this model name. You can easily view all of the Norco Fluid Ht bikes models from 2022, here.
Model range prices
Norco Fluid HT 20.2 2022 is the most economical model, with a starting price of 599$. Norco Fluid HT 1 27.5 2022 on the other hand costs 1749$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Mountain bikes average price
If you want an acceptable Mountain bike you should know that the average price is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 839$. In conclusion, this bike price is 36.2% higher than the price of the average Mountain bike.
Fluid HT+ 4.3 components
Fork
Norco Fluid HT+ 4.3 2022 bike is equipped with the Suntour XCM fork, and has 80mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The Fluid HT+ 4.3 2022 bike is equipped with 24″ aluminum wheels when leaving the factory. The 24″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
