Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 110mm -
Fork RockShox Pike RC
-
Groupset XT, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Optic Aluminum 110mm (29), 120mm (650B)
Suspension Fork
Rockshox Pike RC Solo Air Boost 120mm (29), 130mm (650B)
Rear Shock
Fox Performance Float, DPS SV, EVOL
Drivetrain
Rear Derailleur
Shimano XT M-8000 Shadow Plus 11 sp
Front Derailleur
N/A
Shift Levers
Shimano XT SL-M8000 11 speed
Cassette
Shimano SLX M-7000 11-46T
Crank
Race Face Aeffect w/ steel 30T (29), 32T (650B)
Bottom Bracket
Race Face BB for 73mm threaded BB shell
Chain
KMC 11 speed
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
Shimano Deore boost 110x15
Rear Hub
Shimano Deore boost rear hub
Rims
Race Face AR 27 w/27mm inner
Spokes
Stainless steel
Tires
Schwalbe Nobby Nic 2.35 SnakeSkin Fld, TL easy
Brakes
Brakes
Shimano Deore 6000 w/180mm rotor
Brake Levers
Shimano Deore 6000
Cockpit
Stem
Alloy 6061 w/35mm bar bore, 50mm (29), 60mm (650B)
Handlebar
Norco 20 mm rise 6061 760/780mm, 35mm bar bore
Grips
SDG Stage 1 lock on
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
SDG Duster Mtn
Seatpost
JD Trans X post 80mm XS, 100mm S, 125mm M, 150mm L/XL, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.36 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 332 mm | 332 mm | 332 mm | 332 mm |
| Front Center | 692 mm | 717 mm | 743 mm | 769 mm |
| Rake | 52 mm | 51 mm | 50 mm | 50 mm |
| Trail | 92 mm | 93 mm | 94 mm | 94 mm |
| Stack | 594 mm | 591 mm | 600 mm | 610 mm |
| Reach | 407 mm | 434 mm | 457 mm | 479 mm |
| Top Tube Length | 564 mm | 595 mm | 625 mm | 655 mm |
| Seat Tube Angle | 75.4 ° | 74.9 ° | 74.5 ° | 74.1 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 93 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 418 mm | 423 mm | 428 mm | 433 mm |
| Wheelbase | 1107 mm | 1137 mm | 1168 mm | 1199 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm | 39 mm |
| Standover Height | 754 mm | 746 mm | 751 mm | 766 mm |
| Front Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Rear Travel | 110 mm | 110 mm | 110 mm | 110 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Optic A1 29 completes the Norco Optic model. 96 bikes variations carry this model name so far. You can easily view all of the Norco Optic bikes models from 2018, here.
Model range prices
Norco Optic A3 Womens 27.5 2018 is the most affordable bike of this model and has a price of 2299$. On the other hand, Norco Optic C1 29 2018, is the most expensive and costs 6999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Crosscountry bikes average price
According to our calculations, the average cost of a Crosscountry bike that is reliable is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3299$. If we compare this with the average Crosscountry bike cost we notice that the price is 73.18% more expensive.
Optic A1 29 components
Fork
The RockShox Pike RC is included from the factory. It has a travel distance of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Norco Optic A1 29 bike has the Fox Performance Float model installed, and has a travel of 110mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
When leaving the production line, the Optic A1 29 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Optic A1 29 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
