Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 125mm -
Fork Fox Performance Elite Float 36
-
Groupset XTR, e*thirteen TRS Race -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle, Aluminum Rear, 125mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
Fox Performance Elite FLOAT 36, GRIP2, 140mm Travel, 42mm Offset
Rear Shock
Fox Performance Elite FLOAT X, 190x45mm
Drivetrain
Rear Derailleur
Shimano XTR M9100
Shift Levers
Shimano XTR M9100 I-Spec EV
Cassette
Shimano XTR M9100, 10-51T, 12 Speed
Crank
e*thirteen TRS Race Carbon, 32T, 170mm
Bottom Bracket
e*thirteen BB92
Chain
Shimano XTR M9100
Wheels
Front Hub
Shimano XT HB-8110-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano XT FH-8110-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stan's Flow S1 29", 32H
Tires
Front: Vittoria Mazza 2.4" Trail G2.0, Rear: Vittoria Mazza 2.4" Trail G2.0
Brakes
Brakes
Front: Shimano XTR M9120, 4 Piston, Organic Pads, Rear: Shimano XTR M9120, 4 Piston, Organic Pads
Brake Levers
Shimano XTR
Cockpit
Stem
6061 Alloy, 45mm Length, 35mm Clamp
Handlebar
OneUp Carbon, 800mm, 20mm Rise
Grips
DMR Deathgrip
Headset
FSA Internal Sealed Bearing
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (s), 150mm (M,L), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.38 mm | 1.31 mm | 1.25 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 735 mm | 769 mm | 803 mm | 838 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 606 mm | 615 mm | 624 mm | 633 mm |
| Reach | 415 mm | 445 mm | 475 mm | 505 mm |
| Top Tube Length | 567 mm | 600 mm | 632 mm | 664 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 395 mm | 415 mm | 445 mm | 485 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 420 mm | 425 mm | 430 mm | 435 mm |
| Wheelbase | 1152 mm | 1191 mm | 1230 mm | 1270 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 659 mm | 675 mm | 693 mm | 714 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
About this model
Optic C1 is a Norco Optic model. Norco released 96 bikes variations of this model so far. Take a sneak peek at all Norco Optic bikes models from 2023, by clicking here.
Model range prices
Norco Optic C3 2023 is the most economical model, with a starting price of 3699$. Norco Optic C AXS 2023 on the other hand costs 7199$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Norco released this model in 2023, its price was 5999$. If we compare this with the average Trail bike cost we notice that the price is 117.2% higher.
Optic C1 components
Fork
This bike has the Fox Performance Elite Float 36 fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Optic C1 bike has the Fox Performance Elite FLOAT X model installed, and has a travel of 125mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The wheels on Optic C1 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
