Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 110mm -
Fork RockShox Pike RC
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Optic, Carbon Front Triangle, Aluminum Chainstay, Seat Stay and Linkarm, 110mm (29") | 120mm (27.5") Travel, Boost 12x148mm TA Dropouts
Suspension Fork
RockShox Pike RC, 130mm (29") | 140mm (27.5") Travel, Boost 15x110mm TA, Charger 2 Damper
Rear Shock
Fox Float DPS Performance Elite, 190x50.8mm, EVOL
Drivetrain
Rear Derailleur
SRAM NX Eagle, 12 Speed
Front Derailleur
-
Shift Levers
Rear: SRAM NX Eagle, 12 Speed, Front: -
Cassette
SRAM NX Eagle PG-1230, 11-50T, 12 Speed
Crank
SRAM NX Eagle, 170mm (XS/S) | 175mm (M/L/XL), 32T
Bottom Bracket
SRAM DUB BB, PF92
Chain
SRAM NX Eagle, 12 Speed
Chain Guide
None
Pedals
None
Wheels
Front Hub
Novatec D711SB Boost 110x15 sealed bearing disc hub
Rear Hub
DT Swiss 370, Boost 12x148mm
Rims
WTB ST i29 TCS 2.0, 32 Hole, 29mm Internal Width
Spokes
Sapim, butted, stainless steel
Tires
Maxxis Minion DHF, 2.3", EXO/TR, Folding
Brakes
Brakes
SRAM Level T, 2 Piston Hydraulic Disc, SRAM CenterLine 180mm Rotor
Brake Levers
SRAM Level T
Cockpit
Stem
Alloy 6061 35mm bar bore, 50mm 29, 60mm 650B
Handlebar
Norco 20 mm rise 6061, 35mm bar bore 800mm x 20mm rise
Grips
Ergon GA20, Black
Headset
FSA No 42E/ACB 1.5” to 1-1/8” w/black FSA logos
Seat
Saddle
SDG Radar Mtn saddle
Seatpost
TranzX YSP12JL Stealth Dropper, 80mm (XS) | 100mm (S) | 125mm (M) | 150mm (L/XL) Travel, 31.6mm, 1x Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.39 mm | 1.34 mm | 1.29 mm |
| Bottom Bracket Height | 336 mm | 336 mm | 336 mm | 336 mm |
| Front Center | 695 mm | 720 mm | 746 mm | 773 mm |
| Rake | 47 mm | 46 mm | 45 mm | 45 mm |
| Trail | 101 mm | 102 mm | 103 mm | 103 mm |
| Stack | 597 mm | 595 mm | 604 mm | 613 mm |
| Reach | 402 mm | 429 mm | 452 mm | 474 mm |
| Top Tube Length | 567 mm | 597 mm | 626 mm | 655 mm |
| Seat Tube Angle | 74.7 ° | 74.4 ° | 74 ° | 73.7 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 93 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 418 mm | 423 mm | 428 mm | 433 mm |
| Wheelbase | 1106 mm | 1136 mm | 1167 mm | 1198 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 754 mm | 746 mm | 751 mm | 766 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Optic C2 29 is part of the Norco Optic model. 96 bikes variations carry this model name so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Norco Optic A1 Women’s 29 2019 is the most economical model, with a starting price of 3499$. Norco Optic C1 29 2019 on the other hand costs 5249$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3999$. If we compare this with the average Crosscountry bike cost we notice that the price is 109.92% higher.
Optic C2 29 components
Fork
The Optic C2 29 comes factory-installed with the RockShox Pike RC fork. This has a travel range of 130mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
The shock that’s installed on this bike is Fox Float DPS Performance Elite, with a travel distance of 110mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The Optic C2 29 2019 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Optic C2 29 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
