Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 125mm -
Fork Fox Performance Elite Float 36
-
Groupset XT, Praxis -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle, Aluminum Rear, 125mm Travel, Ride Aligned™
Suspension Fork
Fox Performance Elite 36 Grip2 FLOAT 140mm Travel, 42mm Offset
Rear Shock
Fox Performance Elite FLOAT DPX2, 190x45mm
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano XT Sl-M8100 I-Spec
Cassette
Shimano XT CS-M8100, 10-51T, 12 Speed
Crank
Praxis Girder Carbon M30, 32T, 170mm
Bottom Bracket
Praxis M30 BB92
Chain
Shimano XT CN-M8100
Wheels
Front Hub
Shimano XT HB-8110-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano XT FH-8110-B 12x148mm Boost, 32H, Micro Spline, Center Lock
Rims
Stan's Flow S1 29", 32H
Tires
Vittoria Mazza 2.4" Trail G2.0
Brakes
Brakes
Shimano XT BR-M8020, 4 Piston
Brake Levers
Shimano XT BR-M8020
Disk Rotors
Shimano SM-RT70 Ice Tech, 203mm
Cockpit
Stem
Norco 6061 Alloy, 45mm Length, 35mm Clamp
Handlebar
Butted 6061 Alloy, 780mm, 20mm Rise
Grips
DMR Deathgrip
Headset
FSA Internal Sealed Bearing
Seat
Seatpost
X-Fusion Manic dropper, 31.6mm, 125mm (S), 150mm (M,L), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.38 mm | 1.31 mm | 1.25 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 735 mm | 769 mm | 803 mm | 838 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 606 mm | 615 mm | 624 mm | 633 mm |
| Reach | 415 mm | 445 mm | 475 mm | 505 mm |
| Top Tube Length | 567 mm | 600 mm | 632 mm | 664 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 395 mm | 415 mm | 445 mm | 485 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 420 mm | 425 mm | 430 mm | 435 mm |
| Wheelbase | 1152 mm | 1191 mm | 1230 mm | 1270 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 659 mm | 675 mm | 693 mm | 714 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
About this model
Optic C2 Shimano is a Norco Optic model. 96 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Norco Optic C3 2021 is the most economical model, with a starting price of 4099$. Norco Optic C AXS 2021 on the other hand costs 10499$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5099$. Comparing the average cost of a Trail bike to this one, you will see that Optic C2 Shimano price is 84.61% higher.
Overview of components
Fork
Norco Optic C2 Shimano 2021 bike is equipped with the Fox Performance Elite Float 36 fork, and has 140mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The Optic C2 Shimano has a rear shock with a travel of 125mm. The model Fox Performance Elite FLOAT DPX2 is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
When leaving the production line, the Optic C2 Shimano model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
When you want to stop the bike in time, the brakes are vital. The Optic C2 Shimano has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Optic C2 Shimano comes in 4 sizes, that range from 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Norco model is also equipped with a dropper post. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
