Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 140mm -
Travel Rear 125mm -
Fork RockShox Pike Select+
-
Groupset GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Front Triangle, Aluminum Rear, 125mm Travel, UDH, Hangerless Interface Compatible, Ride Aligned™
Suspension Fork
RockShox Pike Select + RC, DebonAir, 140mm Travel, 42mm Offset
Rear Shock
RockShox Super Deluxe Ultimate DH Custom RC, 190x45mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
SRAM XG1275 Eagle, 10-52T
Crank
SRAM GX Eagle DUB Lunar, 32T, 170mm
Bottom Bracket
SRAM DUB PF92
Chain
SRAM GX Eagle
Wheels
Front Hub
DT Swiss 350 15x110mm Boost, 6 Bolt
Rear Hub
DT Swiss 350 12x148mm Boost, XD, 6 Bolt
Rims
Stan's Flow S1 29", 32H
Tires
Front: Vittoria Mazza 2.4" Trail G2.0, Rear: Vittoria Mazza 2.4" Trail G2.0
Brakes
Brakes
Front: SRAM DB8, 4 Piston, Organic Pads, Rear: SRAM DB8, 4 Piston, Organic Pads
Brake Levers
SRAM DB8
Cockpit
Stem
6061 Alloy, 45mm Length, 35mm Clamp
Handlebar
e*thirteen, 800mm, 20mm Rise
Grips
WTB Waffle Lock-On
Headset
FSA Internal Sealed Bearing
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (S), 150mm (M,L), 170mm (XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.38 mm | 1.31 mm | 1.25 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 337 mm | 337 mm |
| Front Center | 735 mm | 769 mm | 803 mm | 838 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 129 mm | 129 mm | 129 mm | 129 mm |
| Stack | 606 mm | 615 mm | 624 mm | 633 mm |
| Reach | 415 mm | 445 mm | 475 mm | 505 mm |
| Top Tube Length | 567 mm | 600 mm | 632 mm | 664 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 395 mm | 415 mm | 445 mm | 485 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 420 mm | 425 mm | 430 mm | 435 mm |
| Wheelbase | 1152 mm | 1191 mm | 1230 mm | 1270 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 659 mm | 675 mm | 693 mm | 714 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
About this model
Optic C2 SRAM is a Norco Optic model. Norco released 96 bikes variations of this model so far. Take a sneak peek at all Norco Optic bikes models from 2023, by clicking here.
Model range prices
Norco Optic C3 2023 is the most economical model, with a starting price of 3699$. Norco Optic C AXS 2023 on the other hand costs 7199$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2023, its price was 4699$. Comparing this to the average Trail bike price, we see that the price is 70.13% more expensive.
Optic C2 SRAM components
Fork
Norco Optic C2 SRAM 2023 bike is equipped with the RockShox Pike Select+ fork, and has 140mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
As for the rear shock, this bike has the RockShox Super Deluxe Ultimate DH Custom RC model, with a travel of 125mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Optic C2 SRAM 2023 bike is equipped with 29″ aluminum wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Norco Optic C2 SRAM bike has 4 sizes, in the range of 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
The Norco model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
