Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum with custom tube shapes
Suspension Fork
SR Suntour M2000N 63mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD TX-51 7 speed
Front Derailleur
Shimano FD C050 31.8
Shift Levers
Shimano ST-EF50 EZ-Fire, 7 speed front and rear
Cassette
Shimano MF-TZ07, 7 speed, 14-28T
Crank
SR Suntour CW-XCCT102PB, 42/32/22T black /silver alloy
Bottom Bracket
SR Suntour BB-8 XCT SQS cartridge BB
Chain
KMC Z-50
Pedals
MTB resin body
Wheels
Front Hub
Formula alloy, with QR, disc mount
Rear Hub
Formula alloy with QR . for thread on FW
Rims
“Strong” model alloy with CNC sides, 36 hole
Spokes
UCP 2.0
Tires
Innova MTB 26 x 2.10
Brakes
Brakes
Tektro 837 alloy V brake
Brake Levers
Shimano EF-50 brake/ shifter
Cockpit
Stem
MTB alloy threadless 1-1/8 stem
Handlebar
MTB 30 mm rise bar , sand blast black
Grips
MTB design krayton rubber
Headset
CH 281 threadless
Seat
Saddle
Norco MTB saddle, custom cover design
Seatpost
Alloy micro adjust 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 12.5" | 15" | 17" | 18.5" | 20" | 22" |
|---|---|---|---|---|---|---|
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 619 mm | 624 mm | 639 mm | 650 | 660 mm | 670 mm |
| Top Tube Length | 543 mm | 558 mm | 573 mm | 588 mm | 603 mm | 618 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 318 mm | 381 mm | 432 mm | 470 mm | 508 mm | 559 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1049 mm | 1054 mm | 1070 mm | 1080 mm | 1090 mm | 1100 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm | 48 mm |
| Standover Height | 700 | 726 mm | 750 mm | 769 mm | 792 mm | 823 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" | 26" |
About this model
PINNACLE completes the Norco Pinnacle model. Norco launched 6 bikes of this model so far. Check out the entire range from 2009 of this model, by clicking this link.
Model range prices
Norco PINNACLE 2009 is the cheapest bike model and costs 350$. Norco PINNACLE W 2009 is the most expensive one and costs 350$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Norco released this model in 2009, its price was 350$. Doing a quick comparison, we notice that PINNACLE price is 444.29% smaller than the average cost of a Crosscountry bike.
Overview of components
Fork
This bike has the SunTour fork installed. The fork’s travel is 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Norco PINNACLE 2009, has a 26″ aluminum model. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The PINNACLE comes with Rim brakes. Rim brakes deliver an average performance overall. However, you could spend a little extra and get a bike that has hydraulic brakes.
