Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 63mm -
Fork SunTour
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum with custom tube shapes
Suspension Fork
SR Suntour M2000N 63mm travel
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano RD TX-51 7 speed
Front Derailleur
Shimano FD C050 31.8
Shift Levers
Shimano ST-EF50 EZ-Fire, 7 speed front and rear
Cassette
Shimano MF-TZ07, 7 speed, 14-28T
Crank
SR Suntour CW-XCCT102PB, 42/32/22T black /silver alloy
Bottom Bracket
SR Suntour BB-8 XCT SQS cartridge BB
Chain
KMC Z-50
Pedals
MTB resin body
Wheels
Front Hub
Formula alloy, with QR, disc mount
Rear Hub
Formula alloy with QR . for thread on FW
Rims
“Strong” model alloy with CNC sides, 36 hole
Spokes
UCP 2.0
Tires
Innova MTB 26 x 2.10
Brakes
Brakes
Tektro 837 alloy V brake
Brake Levers
Shimano EF-50 brake/ shifter
Cockpit
Stem
MTB alloy threadless 1-1/8 stem
Handlebar
MTB 30 mm rise bar , sand blast black
Grips
MTB design krayton rubber
Headset
CH 281 threadless
Seat
Saddle
Norco MTB saddle, custom cover design
Seatpost
Alloy micro adjust 27.2 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 15" | 17" |
|---|---|---|---|
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 631 mm | 625 mm | 635 mm |
| Top Tube Length | 543 mm | 548 mm | 563 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° |
| Head Tube Length | 125 mm | 125 mm | 125 mm |
| Chainstay Length | 428 mm | 428 mm | 428 mm |
| Wheelbase | 1057 mm | 1051 mm | 1060 mm |
| Bottom Bracket Drop | 48 mm | 48 mm | 48 mm |
| Standover Height | 684 mm | 673 mm | 656 mm |
| Wheels | 26" | 26" | 26" |
Model Overview
PINNACLE W is a Norco Pinnacle model. Norco launched 6 bikes of this model so far. You can easily view all of the Norco Pinnacle bikes models from 2009, here.
Model range prices
Norco PINNACLE W 2009 is the cheapest bike model and costs 350$. Norco PINNACLE 2009 is the most expensive one and costs 350$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Norco released this model in 2009, its price was 350$. Comparing the average cost of a Crosscountry bike to this one, you will see that PINNACLE W price is 444.29% smaller.
PINNACLE W components
Fork
The PINNACLE W comes factory-installed with the SunTour fork. This has a travel range of 63mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
As for the wheels, Norco PINNACLE W 2009, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The PINNACLE W has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
