Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 160mm -
Fork Fox Performance Float 36
-
Groupset GX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Range aluminum frame w/160mm travel
Suspension Fork
Fox 36 Performance 170mm 15mm 3 pos.
Rear Shock
Fox Performance Float 3 pos LV EVOL
Drivetrain
Rear Derailleur
SRAM GX
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM XG 1150 10-42T
Crank
Race Face Aeffect 1x11 30T
Bottom Bracket
Race Face threaded for 73mm shell
Chain
SRAM PC 1130 chain
Chain Tensioner
Black Spire EinFact upper guide
Pedals
Alloy Flat pedal, steel pins
Wheels
Front Hub
Formula alloy MTB w/disc 15 mm axle
Rear Hub
SRAM MTH 746 w XD driver
Rims
Alex MD 27 /32.4 outer tubeless ready
Tires
N/A
Brakes
Brakes
Shimano Deore M615 hydraulic disc w/180mm rtr
Brake Levers
Shimano Deore M615
Disk Rotors
Shimano rear SLX 180 mm 6 bolt
Cockpit
Stem
Short reach stem 45mm or 55mm ext
Handlebar
Norco 6061 alloy DB 25mm rise bar 780mm
Grips
Norco lock on
Headset
Cane Creek 10 Series
Seat
Saddle
WTB Volt Sport saddle
Seatpost
Rockshox Reverb seatpost 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.52 mm | 1.47 mm | 1.42 mm | 1.38 mm |
| Bottom Bracket Height | 345 mm | 345 mm | 345 mm | 345 mm | 345 mm |
| Front Center | 681 mm | 706 mm | 729 mm | 752 mm | 777 mm |
| Rake | 41 mm | 41 mm | 42 mm | 41 mm | 41 mm |
| Trail | 125 mm | 125 mm | 124 mm | 125 mm | 125 mm |
| Stack | 583 mm | 593 mm | 602 mm | 611 mm | 620 mm |
| Reach | 370 mm | 391 mm | 409 mm | 429 mm | 450 mm |
| Top Tube Length | 543 mm | 570 mm | 596 mm | 623 mm | 650 |
| Seat Tube Angle | 73.5 ° | 73.2 ° | 72.8 ° | 72.4 ° | 72.1 ° |
| Seat Tube Length | 380 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 416 mm | 420 mm | 424 mm | 429 mm | 433 mm |
| Wheelbase | 1097 mm | 1126 mm | 1153 mm | 1181 mm | 1210 mm |
| Bottom Bracket Drop | 7 mm | 7 mm | 7 mm | 7 mm | 7 mm |
| Standover Height | 756 mm | 742 mm | 768 mm | 757 mm | 780 mm |
| Front Travel | 170 mm | 170 mm | 170 mm | 170 mm | 170 mm |
| Rear Travel | 160 mm | 160 mm | 160 mm | 160 mm | 160 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Range A7.1 is part of the Norco Range model. Norco released 82 bikes variations of this model so far. Check out the entire range from 2016 of this model, by clicking this link.
Model range prices
Norco Range A7.2 2016 is the most economical model, with a starting price of 2750$. Norco Range C7.1 2016 on the other hand costs 7250$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Enduro bikes
Our math shows that the average cost of a dependable Enduro bike is 3599$. However, even though the average price of an Enduro bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3650$. Comparing this to the average Enduro bike price, we see that the price is 1.42% higher.
Range A7.1 components
Fork
The fork installed on this bike is the Fox Performance Float 36 model. The travel on this model is 170mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
From the factory, it comes with the Fox Performance Float 3 pos LV EVOL rear shock model, which has a travel of 160mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
As for the wheels, Norco Range A7.1 2016, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Range A7.1 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Norco Range A7.1 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Norco Range A7.1 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
