Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset X1, X01 -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC Mid-Mod 27.5
Suspension Fork
Rock Shox Sid RLT 27.5Ó 100mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X1 11spd
Front Derailleur
N/A
Shift Levers
Jagwire
Cassette
SRAM XG1175 10/42 11spd
Crank
SRAM X01 DM Carbon 1x11 32T
Bottom Bracket
SRAM PF30
Chain
SRAM PC-1130 11spd
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss X1700 Spline Two Wheelset
Rear Hub
DT Swiss X1700 Spline Two Wheelset
Rims
DT Swiss
Tires
N/A
Brakes
Brakes
SRAM Guide RS 160mm
Brake Levers
SRAM Guide RS
Disk Rotors
N/A
Cockpit
Stem
Norco SL Alloy Stem
Handlebar
Norco DB Lite 720mm Flat Bar
Grips
Norco SL Silicon
Headset
Feimin Sealed Internal H/S
Seat
Saddle
SDG Circuit MTN Chromo Rail
Seatpost
Norco SL Alloy Post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.52 mm | 1.48 mm | 1.45 mm | 1.42 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 620.8 mm | 644 mm | 665.8 mm | 687.8 mm | 709.6 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 88 mm | 86 mm | 85 mm | 83 mm | 81 mm |
| Stack | 584.9 mm | 600 mm | 615.2 mm | 630.4 mm | 645.6 mm |
| Reach | 375.9 mm | 395.7 mm | 415.4 mm | 434.9 mm | 454.2 mm |
| Top Tube Length | 543 mm | 570 mm | 597 mm | 624 mm | 651 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 368 mm | 405 mm | 445 mm | 485 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 69.75 ° | 70 ° | 70.25 ° | 70.5 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 424 mm | 426 mm | 429 mm | 431 mm | 434 mm |
| Wheelbase | 1040 mm | 1065 mm | 1090 mm | 1115 mm | 1139 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 727 mm | 747 mm | 792 mm | 819 mm | 847 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Revolver 7.1 is a Norco Revolver model. Norco released 148 bikes variations of this model so far. You can easily view all of the Norco Revolver bikes models from 2016, here.
Model range prices
Norco Revolver 9.3 2016 is the most economical model, with a starting price of 2075$. Norco Revolver 7XX 2016 on the other hand costs 7415$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2016 and its price was 4095$. If we compare this with the average Crosscountry bike cost we notice that the price is 114.96% higher.
Overview of components
Fork
This bike has the RockShox SID fork installed. The fork’s travel is 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Revolver 7.1 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Revolver 7.1 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
