Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox SID
-
Groupset X1, X01 -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver Carbon 7.1 FS high modulus frame, 100mm travel
Suspension Fork
Rock Shox Sid RLT 27.5" 100mm/15mm
Rear Shock
Fox Float CTD
Drivetrain
Rear Derailleur
SRAM X1 11 sp long cage
Front Derailleur
N/A
Shift Levers
Jagwire LEX housing
Cassette
SRAM XG 1175 11sp 10-42T
Crank
SRAM X01 DM Carbon 1x11 34T
Bottom Bracket
SRAM Pressfit BB 92
Chain
SRAM PC 1130 11spd chain
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss X1700 Spline Two 27.5 wheelset
Rear Hub
DT Swiss X1700 Spline Two 27.5 Wheelset
Rims
DT Swiss X 1700 Spline Two 27.5 wheelset
Tires
N/A
Brakes
Brakes
SRAM Guide RS 4 piston
Brake Levers
SRAM Guide RS
Disk Rotors
SRAM Centerline 180mm front/ 160mm rear
Cockpit
Stem
Norco Alloy 3D forged stem 7 degree
Handlebar
Norco 6061 DB alloy 740 w/10mm rise
Grips
Norco SL Silicon
Headset
PT 1860A sealed bearing internal w/8mm cover
Seat
Saddle
SDG Circuit MTN with Chromoly Rail
Seatpost
Norco SL 3D forged 2014 alloy 31.6x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.35 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 628 mm | 651 mm | 673 mm | 696 mm | 718 mm |
| Rake | 42 mm | 42 mm | 43 mm | 42 mm | 41 mm |
| Trail | 85 mm | 83 mm | 80 mm | 80 mm | 79 mm |
| Stack | 555 mm | 565 mm | 576 mm | 586 mm | 597 mm |
| Reach | 384 mm | 406 mm | 427 mm | 449 mm | 471 mm |
| Top Tube Length | 534 mm | 561 mm | 588 mm | 615 mm | 642 mm |
| Seat Tube Angle | 75 ° | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° |
| Seat Tube Length | 380 mm | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 419 mm | 421 mm | 424 mm | 428 mm | 432 mm |
| Wheelbase | 1046 mm | 1071 mm | 1097 mm | 1123 mm | 1149 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 736 mm | 748 mm | 742 mm | 736 mm | 727 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Revolver 7.1 FS is a Norco Revolver model. There are 148 bikes that carry this model name. Take a sneak peek at all Norco Revolver bikes models from 2016, by clicking here.
Model range prices
The most economical model, the Norco Revolver 9.3 2016 has a starting price of 2075$. Norco Revolver 7XX 2016 on the other hand is the most expensive at 7415$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
According to our math, the average price for a trustworthy Crosscountry bike is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Revolver 7.1 FS price was 4645$. If we compare this with the average Crosscountry bike cost we notice that the price is 143.83% higher.
Revolver 7.1 FS components
Fork
This bike has the RockShox SID fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float CTD, with a travel distance of 100mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Norco Revolver 7.1 FS 2016, has a 27.5″ aluminum model. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolver 7.1 FS comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
