Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC MId-Modulus Carbon
Suspension Fork
Rock Shox Sid RL 29" 100mm/15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano XT 11spd
Front Derailleur
N/A
Shift Levers
Jagwire
Cassette
Shimano XT M8000 11/42T
Crank
Shimano XT 11spd 32T
Bottom Bracket
Shimano XT w/Truvativ PF30 Adapter
Chain
Shimano HG-600 11spd
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
DT Swiss X1900 Spline TR Wheelset
Rear Hub
DT Swiss X1900 Spline TR Wheelset
Rims
DT Swiss
Tires
N/A
Brakes
Brakes
Shimano XT BRM-8000 160mm
Brake Levers
Shimano XT BRM-8000
Disk Rotors
N/A
Cockpit
Stem
Norco Alloy
Handlebar
Norco Lite 720mm Flat Bar
Grips
Norco SL Silicon
Headset
Tapered
Seat
Saddle
SDG Circuit MTN Steel Rail
Seatpost
Norco Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 79 mm | 77 mm | 75 mm | 74 mm |
| Stack | 616.1 mm | 617.2 mm | 632.4 mm | 647.7 mm |
| Reach | 394.9 mm | 418.7 mm | 438.2 mm | 458.5 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 655 mm |
| Seat Tube Angle | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 440 mm | 442 mm | 445 mm | 447 mm |
| Wheelbase | 1069 mm | 1093 mm | 1118 mm | 1143 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 750 mm | 790 mm | 817 mm | 846 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver 9.2 completes the Norco Revolver model. Norco launched 148 bikes of this model so far. Take a sneak peek at all Norco Revolver bikes models from 2016, by clicking here.
Model range prices
Norco Revolver 9.3 2016 is the most affordable bike of this model and has a price of 2075$. On the other hand, Norco Revolver 7XX 2016, is the most expensive and costs 7415$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3075$. Comparing the average cost of a Crosscountry bike to this one, you will see that Revolver 9.2 price is 61.42% higher.
Revolver 9.2 components
Fork
The fork installed on this bike is the RockShox SID model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Revolver 9.2 are the 27.5″ aluminum type. The 27.5″ wheels are a great choice for smaller riders. However, the overall traction of 27.5″ wheels is lower than 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver 9.2 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
