Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 27.5" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox
-
Groupset XX1, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Revolver 9XX Carbon FS high modulus frame, 100mm travel
Suspension Fork
Rockshox RS 1 29 100mm w/Full Sprint lock
Rear Shock
Rockshox Monarch XX with full sprint
Drivetrain
Rear Derailleur
SRAM XX1 11 sp long cage
Front Derailleur
N/A
Shift Levers
Jagwire ( light weight cable ) rear gear only
Cassette
SRAM XG 1180 11 sp 10-42T
Crank
Race Face Next SL carbon 34T 11 speed
Bottom Bracket
Pressfit BB 92
Chain
SRAM PC 1170 11spd hollow pin
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
DT XRC 1200 Carbon XC 29 wheelset predictive
Rear Hub
DT XCR 1200 carbon wheelset 142x12 XDS 29
Rims
DT XRC 1200 Carbon XC Race wheelset 29er
Tires
N/A
Brakes
Brakes
SRAM Guide Ult. hydraulic disc
Brake Levers
SRAM Guide Ult.
Disk Rotors
SRAM Centerline 180mm front/ 160mm rear
Cockpit
Stem
3T Team Stealth Stem w/ Ti bolts
Handlebar
3T Flat 740 Team Stealth Carbon 31.8 UD mat
Grips
Norco SL Silicon
Headset
Cane Creek 40 series tapered (integrated)
Seat
Saddle
WTB SL-8 Saddle
Seatpost
3T Team Stealth Post Carbon 420 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.33 mm | 1.29 mm | 1.26 mm |
| Bottom Bracket Height | 330 mm | 330 mm | 330 mm | 330 mm |
| Front Center | 666 mm | 687 mm | 710 mm | 732 mm |
| Rake | 51 mm | 52 mm | 50 mm | 52 mm |
| Trail | 73 mm | 71 mm | 71 mm | 67 mm |
| Stack | 575 mm | 576 mm | 587 mm | 597 mm |
| Reach | 408 mm | 432 mm | 454 mm | 475 mm |
| Top Tube Length | 567 mm | 594 mm | 621 mm | 648 mm |
| Seat Tube Angle | 74.75 ° | 74.5 ° | 74.25 ° | 74 ° |
| Seat Tube Length | 410 mm | 445 mm | 485 mm | 530 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 430 mm | 432 mm | 435 mm | 437 mm |
| Wheelbase | 1093 mm | 1117 mm | 1142 mm | 1167 mm |
| Bottom Bracket Drop | 38 mm | 38 mm | 38 mm | 38 mm |
| Standover Height | 768 mm | 758 mm | 753 mm | 745 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Revolver 9XX is part of the Norco Revolver model. Norco released 148 bikes variations of this model so far. You can get a glimpse at all models from 2016, by clicking on this link.
Model range prices
Norco Revolver 9.3 2016 is the cheapest bike model and costs 2075$. Norco Revolver 7XX 2016 is the most expensive one and costs 7415$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Revolver 9XX price was 7415$. In conclusion, this bike price is 289.24% higher than the price of the average Crosscountry bike.
Revolver 9XX components
Fork
This bike has the RockShox fork installed. The fork’s travel is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
The Revolver 9XX has a rear shock with a travel of 100mm. The model Rockshox Monarch XX with full sprint is the one installed in this bike. Rear shocks improve riding comfort and give you greater control over all terrains. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Revolver 9XX are the 27.5″ carbon type. 27.5″ wheels are a mixture between 29″ wheels and 26″ wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Revolver 9XX is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
Revolver 9XX comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
