Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork X-Fusion RC32
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon XC Race, Ride Aligned™
Suspension Fork
X-Fusion RC32 Boost Air, 120mm, 51mm Offset
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100
Shift Levers
Shimano Deore SL-M5100
Cassette
Shimano Deore CS-M5100, 11-51T, 11 Speed
Crank
Shimano Deore FC-M5100-1, 32T, 170mm (S), 175mm (M, L, XL)
Bottom Bracket
Shimano BBMT500PA PF92
Chain
KMC X11
Wheels
Front Hub
Sealed Bearing, 15x110mm Boost, 6 Bolt
Rear Hub
Alloy RR, 12x148mm Boost, HG, 6 Bolt
Rims
Stans Arch D 29" 32H
Tires
Front: Schwalbe Nobby Nic Performance 2.35", Folding Addix, Rear: Schwalbe Nobby Nic Performance 2.35", Folding Addix
Brakes
Brakes
Front: Shimano BRMT400, Resin Pads, Rear: Shimano BRMT400, Resin Pads
Brake Levers
Shimano BRMT400
Cockpit
Stem
Norco SL Alloy Stem, 60mm Length, 31.8mm Clamp
Handlebar
Butted Alloy Lite, 760mm, 15mm Rise
Grips
VP Lock-On
Headset
Angular Cartridge Bearing
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
TranzX YSP18 Dropper, 31.6mm, 130mm (S, M), 150mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.35 mm | 1.28 mm | 1.22 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 706 mm | 736 mm | 770 mm | 803 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 596 mm | 596 mm | 605 mm | 615 mm |
| Reach | 413 mm | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 572 mm | 602 mm | 635 mm | 667 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 425 mm | 440 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.8 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 411 mm | 414 mm | 417 mm | 421 mm |
| Wheelbase | 1111 mm | 1145 mm | 1182 mm | 1219 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 666 mm | 683 mm | 718 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Revolver HT 3 120 is part of the Norco Revolver model. There are 148 bikes that carry this model name. You can easily view all of the Norco Revolver bikes models from 2022, here.
Model range prices
Norco Revolver HT 3 120 2022 is the most economical model, with a starting price of 2799$. Norco Revolver FS AXS 120 2022 on the other hand costs 8699$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2022 for 2799$. Comparing this to the average Trail bike price, we see that the price is 1.34% more expensive.
Overview of components
Fork
The Revolver HT 3 120 comes factory-installed with the X-Fusion RC32 fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
As for the wheels, Norco Revolver HT 3 120 2022, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Revolver HT 3 120 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Revolver HT 3 120 comes in 4 sizes, that range from 154 cm – 191 cm (5.05 ft – 6.27 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the Revolver HT 3 120. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
