Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105, Shimano -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search Mid-Mod Carbon - TA Disc
Suspension Fork
Search Mid-Mod Full Carbon - TA Disc
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105 RD-5800-GS 11spd - Black
Front Derailleur
Shimano 105 FD-5800
Shift Levers
Shift Housing w/Sealed End Caps - Black
Cassette
Shimano 105 CS-5800 11-32T 11 speed
Crank
Shimano FC-RS500 50/34T 11spd - Black
Bottom Bracket
Shimano SM-BB71 Pressfit BB86
Chain
Shimano CN-HG600-11 11speed
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Alloy 15x100mm Thru-Axle Disc 28h - Black
Rear Hub
Alloy 12x142mm Thru-Axle Disc 28h - Black
Rims
Alex ATD470 Disc 28h - Black
Tires
Continental Contact II 28c w/Safety System
Brakes
Brakes
Hayes CX Comp Mech Disc w/160mm rotor
Brake Levers
Shimano 105 ST-5800
Disk Rotors
N/A
Cockpit
Stem
Norco - Black w/Yellow
Handlebar
Ritchey Comp Evo Curve - Black
Grips
Norco UltraComfort w/Vex Gel - Black
Headset
Cane Creek 10-Series w/9mm Top Cover
Seat
Saddle
Norco Sport w/Cromo Rail - Black
Seatpost
Norco - Black w/Yellow
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.5 mm | 1.51 mm | 1.54 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 279.5 mm | 279.5 mm | 282 mm | 282 mm | 284.5 mm | 284.5 mm |
| Front Center | 577 mm | 583 mm | 592 mm | 604 mm | 617 mm | 629 mm |
| Rake | 47 mm | 47 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 72 mm | 69 mm | 62 mm | 60 mm | 59 mm | 57 mm |
| Stack | 521 mm | 537 mm | 553 mm | 576 mm | 595 mm | 618 mm |
| Reach | 354 mm | 359 mm | 367 mm | 375 mm | 384 mm | 391 mm |
| Top Tube Length | 503.5 mm | 516 mm | 533.5 mm | 551 mm | 568.5 mm | 586 mm |
| Seat Tube Angle | 74.75 ° | 74.25 ° | 73.5 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 425 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 70.75 ° | 71.25 ° | 72 ° | 72.25 ° | 72.5 ° | 72.75 ° |
| Head Tube Length | 115 mm | 130 mm | 147.5 mm | 170 mm | 192.5 mm | 215 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 982 mm | 988 mm | 998 mm | 1010 mm | 1024 mm | 1036 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm | 67 mm |
| Standover Height | 704 mm | 721 mm | 747 mm | 769 mm | 792 mm | 817 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Search 105 completes the Norco Search model. 121 bikes variations carry this model name so far. Take a sneak peek at all Norco Search bikes models from 2015, by clicking here.
Model range prices
The most economical model, the Norco Search S3 2015 has a starting price of 885$. Norco Search XR 2015 on the other hand is the most expensive at 3700$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2015 for 2110$. Doing a quick comparison, we notice that Search 105 price is 16.68% smaller than the average cost of a Gravel bike.
Search 105 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
When it comes to wheels, the Search 105 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Search 105 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
