Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search X6 Double Butted Aluminum
Suspension Fork
Search Carbon
Drivetrain
Rear Derailleur
Shimano 105 RD-5800-GS 11spd
Front Derailleur
Shimano 105 FD-5801 11spd
Shift Levers
Rear: Shimano 105 ST-5800 11spd - Black, Front: Shimano 105 ST-5800 2spd - Black
Cassette
Shimano 105 CS-5800 11spd 11-32T
Crank
Praxis Alba 48/32T
Bottom Bracket
Praxis M30
Chain
KMC X11
Wheels
Front Hub
Alloy 15x100mm Thru-Axle 28h - Black
Rear Hub
Alloy 10x135mm 28h - Black
Rims
WTB SX19 - Black
Tires
Clement Strada USH 32c - Folding
Brakes
Brakes
TRP Spyre C Twin Piston Mech Disc - 160mm
Brake Levers
Shimano 105 ST-5800 - Black
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Norco Flare - Black
Grips
Norco Super Griptacular w/Gel - Black
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco Race - Black
Seatpost
Norco 27.2mm - Black Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.48 mm | 1.51 mm | 1.53 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 272.5 mm | 272.5 mm | 275 mm | 275 mm | 277.5 mm | 277.5 mm |
| Front Center | 582 mm | 588 mm | 592 mm | 604 mm | 617 mm | 629 mm |
| Rake | 49 mm | 49 mm | 48 mm | 49 mm | 49 mm | 49 mm |
| Trail | 70 mm | 67 mm | 63 mm | 60 mm | 59 mm | 57 mm |
| Stack | 520 mm | 536 mm | 553 mm | 575 mm | 595 mm | 618 mm |
| Reach | 357 mm | 362 mm | 367 mm | 375 mm | 384 mm | 391 mm |
| Top Tube Length | 501 mm | 516 mm | 533.5 mm | 551 mm | 568.5 mm | 586 mm |
| Seat Tube Angle | 74.75 ° | 74.25 ° | 73.5 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 425 mm | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 70.75 ° | 71.25 ° | 72 ° | 72.25 ° | 72.5 ° | 72.75 ° |
| Head Tube Length | 115 mm | 130 mm | 147.5 mm | 170 mm | 192.5 mm | 215 mm |
| Chainstay Length | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm | 416 mm |
| Wheelbase | 987 mm | 993 mm | 997 mm | 1010 mm | 1024 mm | 1036 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 67 mm | 67 mm |
| Standover Height | 711 mm | 729 mm | 751 mm | 779 mm | 805 mm | 828 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Search A 105 Mech completes the Norco Search model. Norco launched 121 bikes of this model so far. Take a sneak peek at all Norco Search bikes models from 2018, by clicking here.
Model range prices
Norco Search A Claris 2018 is the cheapest bike model and costs 749$. Norco Search XR Force 1 2018 is the most expensive one and costs 4199$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Norco Search A 105 Mech price was 1349$. If we compare this with the average Gravel bike cost we notice that the price is 82.51% lower.
Search A 105 Mech components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
When leaving the production line, the Search A 105 Mech model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Search A 105 Mech has Mechanical Disc brakes. They are much easier to maintain than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
