Norco Search XR Aluminum Apex 1 650b 2019
2019 Road
Estimate price |
1,599$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Apex 1, Praxis -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco Search XR, Aluminum, 12x142mm TA Dropouts
Suspension Fork
Norco Search XR Carbon Fork, 12x100mm TA
Drivetrain
Rear Derailleur
SRAM Apex 1, Long Cage, 11 Speed
Shift Levers
Rear: SRAM Apex 1, 11 Speed, Front: SRAM Apex 1, 2 Speed
Cassette
SRAM NX PG-1130, 11-42T, 11 Speed
Crank
Praxis Alba M24, 170mm (48/50.5) | 172.5mm (53/55.5) | 175mm (58/60.5), 40T
Bottom Bracket
Praxis M24 PressFit, BB86
Chain
SRAM Apex 1 PC-1110, 11 Speed
Wheels
Front Hub
Alloy 12x100mm Thru-Axle 32h - Black
Rear Hub
Alloy, 32 Hole, 12x142mm
Rims
WTB ASYM i23 TCS, 23mm Internal Width
Tires
Schwalbe G-One Bite, 38c, RaceGuard, Folding
Brakes
Brakes
TRP Spyre C, 2 Piston Mechanical Disc, 160mm Rotor
Brake Levers
SRAM Apex 1
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Norco Super Flare 16deg - Black
Headset
FSA Orbit No. 42/ACB - All Black
Seat
Saddle
Norco Race w/Chromo Rails - Charcoal
Seatpost
Norco SL Alloy, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm |
|---|---|
| Stack Reach Ratio | 1.45 mm |
| Bottom Bracket Height | 275 mm |
| Front Center | 578 mm |
| Rake | 49 mm |
| Trail | 62 mm |
| Stack | 525 mm |
| Reach | 363 mm |
| Top Tube Length | 516 mm |
| Seat Tube Angle | 73.75 ° |
| Seat Tube Length | 435 mm |
| Head Tube Angle | 71 ° |
| Head Tube Length | 130 mm |
| Chainstay Length | 411 mm |
| Wheelbase | 982 mm |
| Bottom Bracket Drop | 57 mm |
| Standover Height | 721 mm |
| Wheels | 650 |
Model Overview
Search XR Aluminum Apex 1 650b belongs to the Norco Search model. Norco released 121 bikes variations of this model so far. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
Norco Search XR Aluminum Apex 1 650b 2019 is the cheapest bike model and costs 1599$. Norco Search XR Carbon Force 1 650b 2019 is the most expensive one and costs 4599$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2019 for 1599$. In conclusion, this bike price is 53.97% smaller than the price of the average Gravel bike.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
The Search XR Aluminum Apex 1 650b 2019 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
When you want to stop the bike in time, the brakes are vital. The Search XR Aluminum Apex 1 650b has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
