Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 650b / 700c -
Groupset Apex 1 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search XR Carbon
Suspension Fork
Search XR Carbon
Drivetrain
Rear Derailleur
SRAM Apex 1 Long Cage
Front Derailleur
Norco Integrated 1x Guide
Shift Levers
SRAM Apex 1 11spd w/Hydro Disc
Cassette
SRAM XG-1150 10-42T
Crank
SRAM Apex 1 40T - Black
Bottom Bracket
Enduro GXP Pressfit86
Chain
SRAM PC-1110
Wheels
Front Hub
Alloy 12x100mm Thru-Axle 28h - Black
Rear Hub
Alloy 12x142mm Thru-Axle 28h - Black
Rims
WTB STS i23 - Black
Tires
Clement X’Plor MSO 650Bx42c(45.5/48) or 700x40c(50.5-60.5) - Folding / Tubeless Ready
Brakes
Brakes
SRAM Apex 1 Hydraulic Disc w/160mm Rotor
Brake Levers
SRAM Apex 1 Hydraulic Disc
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Easton EA70 AX w/16deg Flare
Grips
Norco Microfiber - Brown
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco SL Race w/Chromo Rails - Brown
Seatpost
Norco SL Composite 27.2mm - UD Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.46 mm | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 277 mm | 279.5 mm | 279.5 mm | 282 mm | 282 mm |
| Front Center | 566 mm | 578 mm | 595 mm | 604 mm | 614 mm | 627 mm | 639 mm |
| Rake | 50 mm | 49 mm | 49 mm | 49 mm | 50 mm | 49 mm | 49 mm |
| Trail | 62 mm | 62 mm | 68 mm | 65 mm | 62 mm | 62 mm | 60 mm |
| Stack | 497 mm | 517 mm | 540 mm | 556 mm | 573 mm | 593 mm | 613 mm |
| Reach | 348 mm | 355 mm | 369 mm | 376 mm | 383 mm | 392 mm | 400 mm |
| Top Tube Length | 493 mm | 508 mm | 523 mm | 541 mm | 558 mm | 576 mm | 593 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.75 ° | 71 ° | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 110 mm | 130 mm | 120 mm | 138 mm | 155 mm | 178 mm | 198 mm |
| Chainstay Length | 403 mm | 403 mm | 415 mm | 415 mm | 415 mm | 418 mm | 418 mm |
| Wheelbase | 963 mm | 974 mm | 999 mm | 1008 mm | 1019 mm | 1035 mm | 1047 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Standover Height | 694 mm | 713 mm | 738 mm | 760 mm | 781 mm | 806 mm | 829 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Search XR Apex 1 completes the Norco Search model. There are 121 bikes that carry this model name. You can easily view all of the Norco Search bikes models from 2018, here.
Model range prices
The most economical model, the Norco Search A Claris 2018 has a starting price of 749$. Norco Search XR Force 1 2018 on the other hand is the most expensive at 4199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2018, its price was 2899$. Doing a quick comparison, we notice that Search XR Apex 1 price is 17.75% higher than the average cost of a Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
The wheels on Search XR Apex 1 are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Search XR Apex 1 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
