Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search Reynolds 725 Chromoly
Suspension Fork
Search SL High-Modulus Carbon
Drivetrain
Rear Derailleur
Shimano 105 RD-5800-GS 11spd
Front Derailleur
Shimano 105 FD-5801 11spd
Shift Levers
Rear: Shimano 105 ST-5800 11spd - Black, Front: Shimano 105 ST-5800 2spd - Black
Cassette
Shimano 105 CS-5800 11-32T 11 speed
Crank
Praxis Alba 48/32T
Bottom Bracket
Praxis M30 PressFit86
Chain
KMC X11
Wheels
Front Hub
Alloy 12x100mm Thru-Axle 28h - Black
Rear Hub
Alloy 12x142mm Thru-Axle 28h - Black
Rims
WTB STS i23 - Black
Tires
Clement X’Plor MSO 650Bx42c(45.5/48) or 700x40c(50.5-60.5) - Folding / Tubeless Ready
Brakes
Brakes
TRP Spyre C Twin Piston Mech Disc - 160mm
Brake Levers
Shimano 105 ST-5800 - Black
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Norco Flare - Black
Grips
Norco Super Griptacular w/Gel - Black
Headset
Cartridge Bearing
Seat
Saddle
Norco SL Race w/Chromo Rails - Black
Seatpost
Norco 27.2mm - Black Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.47 mm | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 277 mm | 279.5 mm | 279.5 mm | 282 mm | 282 mm |
| Front Center | 567 mm | 578 mm | 595 mm | 604 mm | 614 mm | 627 mm | 639 mm |
| Rake | 49 mm | 49 mm | 50 mm | 50 mm | 49 mm | 49 mm | 50 mm |
| Trail | 63 mm | 62 mm | 67 mm | 64 mm | 63 mm | 62 mm | 59 mm |
| Stack | 500 mm | 519 mm | 542 mm | 556 mm | 576 mm | 593 mm | 613 mm |
| Reach | 348 mm | 355 mm | 368 mm | 376 mm | 383 mm | 392 mm | 400 mm |
| Top Tube Length | 493 mm | 508 mm | 523 mm | 541 mm | 558 mm | 576 mm | 593 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.75 ° | 71 ° | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 100 mm | 120 mm | 110 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 413 mm | 413 mm | 423 mm | 423 mm | 423 mm | 425 mm | 425 mm |
| Wheelbase | 973 mm | 984 mm | 1007 mm | 1016 mm | 1026 mm | 1043 mm | 1055 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Standover Height | 694 mm | 713 mm | 739 mm | 760 mm | 782 mm | 806 mm | 829 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Search XR-S 105 belongs to the Norco Search model. Norco launched 121 bikes of this model so far. You can easily view all of the Norco Search bikes models from 2018, here.
Model range prices
Norco Search A Claris 2018 is the cheapest bike model and costs 749$. Norco Search XR Force 1 2018 is the most expensive one and costs 4199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2018 and its price was 1999$. Comparing this to the average Gravel bike price, we see that the price is 23.16% lower.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The Search XR-S 105 2018 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Search XR-S 105 is equipped with Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
