Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 700c -
Groupset Rival 1, Praxis -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search Reynolds 725 Chromoly
Suspension Fork
Search SL High-Modulus Carbon
Drivetrain
Rear Derailleur
SRAM Rival 1 Long Cage
Shift Levers
Rear: SRAM Rival 1 Hydraulic Disc Brake/11s Shifter, Front: SRAM Rival 1 Hydraulic Disc Brake
Cassette
SRAM XG-1150 10-42T
Crank
Praxis Zayante 40T
Bottom Bracket
Praxis M30 PressFit86
Chain
SRAM PC-1110
Wheels
Front Hub
Alloy 12x100mm Thru-Axle 28h - Black
Rear Hub
Alloy 12x142mm Thru-Axle 28h - Black
Rims
WTB STS i23 - Black
Tires
Clement X’Plor MSO 650Bx42c(45.5/48) or 700x40c(50.5-60.5) - Folding / Tubeless Ready
Brakes
Brakes
SRAM Rival 1 Hydraulic Disc w/160mm Rotor
Brake Levers
SRAM Rival 1 Hydraulic Disc
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Easton EA70 AX w/16deg Flare
Grips
Norco Super Griptacular w/Gel - Black
Headset
Cartridge Bearing
Seat
Saddle
Norco SL Race w/Chromo Rails - Black
Seatpost
Norco 27.2mm - Black Stealth
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.47 mm | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 277 mm | 279.5 mm | 279.5 mm | 282 mm | 282 mm |
| Front Center | 567 mm | 578 mm | 595 mm | 604 mm | 614 mm | 627 mm | 639 mm |
| Rake | 49 mm | 49 mm | 50 mm | 50 mm | 49 mm | 49 mm | 50 mm |
| Trail | 63 mm | 62 mm | 67 mm | 64 mm | 63 mm | 62 mm | 59 mm |
| Stack | 500 mm | 519 mm | 542 mm | 556 mm | 576 mm | 593 mm | 613 mm |
| Reach | 348 mm | 355 mm | 368 mm | 376 mm | 383 mm | 392 mm | 400 mm |
| Top Tube Length | 493 mm | 508 mm | 523 mm | 541 mm | 558 mm | 576 mm | 593 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.75 ° | 71 ° | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 100 mm | 120 mm | 110 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 413 mm | 413 mm | 423 mm | 423 mm | 423 mm | 425 mm | 425 mm |
| Wheelbase | 973 mm | 984 mm | 1007 mm | 1016 mm | 1026 mm | 1043 mm | 1055 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Standover Height | 694 mm | 713 mm | 739 mm | 760 mm | 782 mm | 806 mm | 829 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Search XR-S Rival belongs to the Norco Search model. Norco launched 121 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Norco Search A Claris 2018 is the cheapest bike model and costs 749$. Norco Search XR Force 1 2018 is the most expensive one and costs 4199$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Norco Search XR-S Rival price was 2599$. In conclusion, this bike price is 5.56% higher than the price of the average Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Norco Search XR-S Rival 2018, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Search XR-S Rival comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
