Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
50.5cm
158cm - 167cm
53cm
165cm - 174cm
55.5cm
171cm - 180cm
58cm
177cm - 186cm
60.5cm
184cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search Reynolds 725 Chromoly Steel
Suspension Fork
Search XR Mid-Modulus Carbon
Drivetrain
Rear Derailleur
Shimano GRX RD-RX810
Front Derailleur
Shimano 105 FD-R7000
Shift Levers
Shimano GRX ST-RX600 11 speed
Cassette
Shimano CS-HG700 11-34T
Crank
Easton EA90 46/30T
Bottom Bracket
Easton PressFit BB86
Chain
KMC X11
Wheels
Front Hub
Sealed Bearing 12x100mm TA
Rear Hub
Sealed Bearing w/Alloy Freehub 12x142mm TA
Rims
WTB ST Light i23 TCS 2.0, Tubeless Ready
Tires
Front: WTB Resolute TCS 700x42c, Tubeless Compatible System, Tanwall, Rear: WTB Resolute TCS 700x42c, Tubeless Compatible System, Tanwall
Brakes
Brakes
Front: Shimano GRX BR-RX400 Hydraulic Disc, Rear: Shimano GRX BR-RX400 Hydraulic Disc
Brake Levers
Shimano GRX RX600 Hydraulic
Cockpit
Stem
Norco SL Aluminum - Custom Painted
Handlebar
Easton EA70 AX Aluminum, 16deg Flare
Headset
FSA 44mm Cartridge Bearing
Seat
Saddle
Norco SL Race, Cromo Rails
Seatpost
X-Fusion Manic Gravel 50mm Dropper, Drop-Bar Remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.48 mm | 1.51 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 277 mm | 280 mm | 280 mm | 282 mm | 282 mm |
| Front Center | 595 mm | 604 mm | 613 mm | 627 mm | 639 mm |
| Rake | 49 mm | 49 mm | 49 mm | 49 mm | 49 mm |
| Trail | 69 mm | 66 mm | 64 mm | 63 mm | 61 mm |
| Stack | 541 mm | 555 mm | 575 mm | 592 mm | 612 mm |
| Reach | 367 mm | 375 mm | 382 mm | 391 mm | 399 mm |
| Top Tube Length | 522 mm | 540 mm | 557 mm | 575 mm | 592 mm |
| Seat Tube Angle | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 110 mm | 125 mm | 145 mm | 165 mm | 185 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 424 mm | 424 mm |
| Wheelbase | 1006 mm | 1015 mm | 1025 mm | 1042 mm | 1054 mm |
| Bottom Bracket Drop | 75 mm | 72 mm | 72 mm | 70 mm | 70 mm |
| Standover Height | 680 mm | 710 mm | 737 mm | 767 mm | 795 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 165 cm | 171 cm | 177 cm | 184 cm |
| Rider Max Height | 167 cm | 174 cm | 180 cm | 186 cm | 194 cm |
About this model
Search XR S1 700c is part of the Norco Search model. Norco launched 121 bikes of this model so far. You can easily view all of the Norco Search bikes models from 2023, here.
Model range prices
Norco Search XR Flat Bar 2023 is the most economical model, with a starting price of 1349$. Norco Search XR S1 700c 2023 on the other hand costs 3299$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2023, its price was 3299$. Doing a quick comparison, we notice that Search XR S1 700c price is 34% more expensive than the average cost of a Gravel bike.
Search XR S1 700c components
Fork material
Search XR S1 700c has a carbon fork, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
As for the wheels, Norco Search XR S1 700c 2023, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Search XR S1 700c comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Norco Search XR S1 700c bike has 5 sizes, in the range of 158 cm – 194 cm (5.18 ft – 6.36 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Norco model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
