Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 650b / 700c -
Groupset Ultegra, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Search XR Carbon
Suspension Fork
Search XR Carbon
Drivetrain
Rear Derailleur
Shimano Ultegra RD-R8000-GS 11spd
Front Derailleur
Shimano Ultegra FD-R8000
Shift Levers
Rear: Shimano Ultegra ST-R8020 11spd, Front: Shimano Ultegra ST-R8020 2spd
Cassette
Shimano Ultegra CS-HG800 11spd 11-34T
Crank
Praxis Zayante 48/32T
Bottom Bracket
Praxis M30
Chain
KMC X11
Wheels
Front Hub
Clement USHUAiA 100x12mm Sealed Bearing
Rear Hub
Clement USHUAiA 142x12mm Sealed Bearing
Rims
Clement USHUAiA
Tires
Clement X’Plor MSO 650Bx42c(45.5/48) or 700x40c(50.5-60.5) - Folding / Tubeless Ready
Brakes
Brakes
Shimano Ultegra BR-R8070 w/160mm Rotor
Brake Levers
Shimano Ultegra ST-8020 Hydraulic Disc
Cockpit
Stem
Norco SL Alloy - Black
Handlebar
Easton EA70 AX w/16deg Flare
Grips
Norco Super Griptacular w/Gel - Black
Headset
Angular Sealed Cartridge Bearings - Tapered
Seat
Saddle
Norco SL Race w/Crn-Ti Rails - Black
Seatpost
Norco SL Composite 27.2mm - UD Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45.5cm | 48cm | 50.5cm | 53cm | 55.5cm | 58cm | 60.5cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.46 mm | 1.48 mm | 1.5 mm | 1.51 mm | 1.53 mm |
| Bottom Bracket Height | 273 mm | 273 mm | 277 mm | 279.5 mm | 279.5 mm | 282 mm | 282 mm |
| Front Center | 566 mm | 578 mm | 595 mm | 604 mm | 614 mm | 627 mm | 639 mm |
| Rake | 50 mm | 49 mm | 49 mm | 49 mm | 50 mm | 49 mm | 49 mm |
| Trail | 62 mm | 62 mm | 68 mm | 65 mm | 62 mm | 62 mm | 60 mm |
| Stack | 497 mm | 517 mm | 540 mm | 556 mm | 573 mm | 593 mm | 613 mm |
| Reach | 348 mm | 355 mm | 369 mm | 376 mm | 383 mm | 392 mm | 400 mm |
| Top Tube Length | 493 mm | 508 mm | 523 mm | 541 mm | 558 mm | 576 mm | 593 mm |
| Seat Tube Angle | 74 ° | 73.75 ° | 74.25 ° | 73.75 ° | 73.25 ° | 73 ° | 72.75 ° |
| Seat Tube Length | 410 mm | 435 mm | 460 mm | 490 mm | 520 mm | 550 mm | 580 mm |
| Head Tube Angle | 70.75 ° | 71 ° | 71 ° | 71.5 ° | 71.75 ° | 72 ° | 72.25 ° |
| Head Tube Length | 110 mm | 130 mm | 120 mm | 138 mm | 155 mm | 178 mm | 198 mm |
| Chainstay Length | 403 mm | 403 mm | 415 mm | 415 mm | 415 mm | 418 mm | 418 mm |
| Wheelbase | 963 mm | 974 mm | 999 mm | 1008 mm | 1019 mm | 1035 mm | 1047 mm |
| Bottom Bracket Drop | 57 mm | 57 mm | 75 mm | 73 mm | 73 mm | 70 mm | 70 mm |
| Standover Height | 694 mm | 713 mm | 738 mm | 760 mm | 781 mm | 806 mm | 829 mm |
| Wheels | 650 | 650 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Search XR Ultegra belongs to the Norco Search model. Norco released 121 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Norco Search A Claris 2018 is the most economical model, with a starting price of 749$. Norco Search XR Force 1 2018 on the other hand costs 4199$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, this bike was made available in 2018 for 3799$. Doing a quick comparison, we notice that Search XR Ultegra price is 54.31% more expensive than the average cost of a Gravel bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
The Search XR Ultegra 2018 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Search XR Ultegra is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
