Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Fork Fox Float 34
-
Groupset X9 -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2013 Shinobi 29er 120 mm travel
Suspension Fork
Fox Float 34 CTD FIT 140mm , 29er
Rear Shock
Float CTD BV SV - Performance
Drivetrain
Rear Derailleur
SRAM X9 Type 2 ( 10 speed) med cage
Front Derailleur
SRAM X-9 high clamp 2x10 front derailleur
Shift Levers
Jagwire LEX housing
Cassette
SRAM PG 1050 11-36T
Crank
SRAM X9 crank 10 speed 36/22
Bottom Bracket
N/A
Chain
SRAM PC 1031
Chain Tensioner
SRAM 2 x X guide
Pedals
N/A
Wheels
Front Hub
N/A
Rear Hub
N/A
Rims
Sun Black Flag Expert wheelset
Tires
Continental X-King 29 x 2.4 folding bead
Brakes
Brakes
Avid Elixer 9 160 mm rear / 180 mm rear
Brake Levers
Avid HS 1 180 mm rotor
Disk Rotors
N/A
Cockpit
Stem
Race Face Turbine 70 mm on SM/MX 90 on LG/XL
Handlebar
Norco SL 19 mm rise 760 mm width butted
Grips
Ergon GA1 EVO
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
WTB Silverado ( chromoly) (Race SL)
Seatpost
Norco SL double bolt 2014 alloy post 3D forged 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.49 mm | 1.43 mm | 1.38 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Front Center | 669 mm | 695 mm | 721 mm | 747 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 99 mm | 99 mm | 99 mm | 99 mm |
| Stack | 609 mm | 619 mm | 628 mm | 638 mm |
| Reach | 394 mm | 416 mm | 439 mm | 461 mm |
| Top Tube Length | 568 mm | 593 mm | 618 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 445 mm | 480 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1123 mm | 1149 mm | 1175 mm | 1201 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" |
Model Overview
Shinobi 1 is part of the Norco Shinobi model. There are 9 bikes that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Model range prices
Norco Shinobi 3 2013 is the most economical model, with a starting price of 2110$. Norco Shinobi 1 2013 on the other hand costs 4235$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
This bike was released in 2013 and its price was 4235$. If we compare this with the average Trail bike cost we notice that the price is 53.33% more expensive.
Overview of components
Fork
The Fox Float 34 is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Norco Shinobi 1 bike has the Float CTD BV SV – Performance model installed, and has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Shinobi 1 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
