Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 29" -
Travel Front 140mm -
Travel Rear 120mm -
Fork X Fusion
-
Groupset X7, X5 -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2013 Shinobi 120 mm travel
Suspension Fork
X-Fusion Trace RL Air 140 mm 15 mm axle
Rear Shock
X Fusion 02 RL AV ( high volume )
Drivetrain
Rear Derailleur
SRAM X 7 mid cage
Front Derailleur
SRAM X5 high clamp front derailleur
Shift Levers
Jagwire LEX housing
Cassette
SRAM PG 1030 10 speed
Crank
SRAM S-1000 double 36/22
Bottom Bracket
N/A
Chain
SRAM PC 1031
Chain Tensioner
E-13 TRS dual with steel backplate
Pedals
Norco alloy flat pedal Steel insert pins
Wheels
Front Hub
Formula 15 mm front hub
Rear Hub
Formula cassette hub
Rims
Sun Inferno 25 29er rim
Tires
Continental X-King 29 x 2.2
Brakes
Brakes
Avid Elixer 3 hydraulic disc brake 180 rotor
Brake Levers
Avid G2 Clean Sweep rotors 180 mm
Disk Rotors
N/A
Cockpit
Stem
Norco MTB stem 60 mm S/M 70 mm M/L
Handlebar
Norco .5" rise bar 760 mm width PG 6061
Grips
T-One lock on grip black and grey
Headset
FSA #57B ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
Norco trail / all mountain saddle
Seatpost
Norco alloy double bolt seatpost 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - |
|---|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.49 mm | 1.43 mm | 1.38 mm |
| Bottom Bracket Height | 346 mm | 346 mm | 346 mm | 346 mm |
| Front Center | 669 mm | 695 mm | 721 mm | 747 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 99 mm | 99 mm | 99 mm | 99 mm |
| Stack | 609 mm | 619 mm | 628 mm | 638 mm |
| Reach | 394 mm | 416 mm | 439 mm | 461 mm |
| Top Tube Length | 568 mm | 593 mm | 618 mm | 643 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 420 mm | 445 mm | 480 mm | 530 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 456 mm | 456 mm | 456 mm | 456 mm |
| Wheelbase | 1123 mm | 1149 mm | 1175 mm | 1201 mm |
| Bottom Bracket Drop | 27 mm | 27 mm | 27 mm | 27 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 120 mm | 120 mm | 120 mm | 120 mm |
| Wheels | 29" | 29" | 29" | 29" |
About this model
Shinobi 3 is part of the Norco Shinobi model. There are 9 bikes that carry this model name. You can easily view all of the Norco Shinobi bikes models from 2013, here.
Model range prices
Norco Shinobi 3 2013 is the most economical model, with a starting price of 2110$. Norco Shinobi 1 2013 on the other hand costs 4235$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2013 for 2110$. If we compare this with the average Trail bike cost we notice that the price is 30.9% smaller.
Overview of components
Fork
The X Fusion is included from the factory. It has a travel distance of 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Norco Shinobi 3 bike has the X Fusion 02 RL AV ( high volume ) model installed, and has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
When it comes to wheels, the Shinobi 3 bike is equipped with the 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Shinobi 3 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
