Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Float 32
-
Groupset XT, Shimano -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2013 SIGHT frame (140 mm travel)
Suspension Fork
Fox 32 Evolution 140 mm CTD O/C TALAS
Rear Shock
Float CTD BV SV - Performance
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus rear derailleur
Front Derailleur
Shimano XT direct chainstay mount FD
Shift Levers
Shimano
Cassette
Shimano XT cassette
Crank
Shimano XT 2 x 10 38/24T
Bottom Bracket
N/A
Chain
Shimano HG-74
Chain Tensioner
Bionicon C-Guide
Pedals
N/A
Wheels
Front Hub
Shimano XT wheelset
Rear Hub
Shimano XT wheelset
Rims
Shimano XT wheelset
Tires
Continental X King 26 x 2.2 Folding bead
Brakes
Brakes
Shimano XT Resin pad with fins I spec
Brake Levers
XT 180 mm rotor
Disk Rotors
N/A
Cockpit
Stem
Race Face Turbine stem 70 mm black
Handlebar
Race Face Turbine 3/4 rise bar
Grips
Ergon GA1 EVO
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
WTB Volt team saddle with nicro tubular rail
Seatpost
Rockshox Reverb post 380 mm XS/SM 420 M-XL 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.478 mm | 1.415 mm | 1.366 mm | 1.318 mm | 1.273 mm |
| Bottom Bracket Height | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm |
| Front Center | 657 mm | 683 mm | 709 mm | 736 mm | 762 mm |
| Rake | 43 mm | 42 mm | 42 mm | 43 mm | 42 mm |
| Trail | 96 mm | 97 mm | 97 mm | 96 mm | 97 mm |
| Stack | 560 mm | 569 mm | 579 mm | 588 mm | 597 mm |
| Reach | 379 mm | 402 mm | 424 mm | 446 mm | 469 mm |
| Top Tube Length | 540 mm | 565 mm | 590 mm | 615 mm | 640 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1082 mm | 1108 mm | 1134 mm | 1161 mm | 1187 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
Model Overview
Sight 1 is part of the Norco Sight model. 215 bikes variations carry this model name so far. Take a sneak peek at all Norco Sight bikes models from 2013, by clicking here.
Model range prices
Norco Sight 3 2013 is the most economical model, with a starting price of 2350$. Norco Sight Killer B-1 2013 on the other hand costs 5135$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2013, its price was 4865$. Comparing the average cost of a Trail bike to this one, you will see that Sight 1 price is 76.14% higher.
Sight 1 components
Fork
Norco Sight 1 2013 bike is equipped with the Fox Float 32 fork, and has 140mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
As for the rear shock, this bike has the Float CTD BV SV – Performance model, with a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
The wheels on Sight 1 are the 26″ aluminum type. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Sight 1 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
