Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 26" -
Travel Front 140mm -
Travel Rear 140mm -
Fork RockShox Revelation RC
-
Groupset XT, SLX -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
2013 SIGHT frame (140 mm travel)
Suspension Fork
Rockshox Revelation RL 140 , 15 mm axle
Rear Shock
Fox Float CTD SV (No BV) - Evolution
Drivetrain
Rear Derailleur
Shimano XT Shadow Plus rear derailleur
Front Derailleur
Shimano SLX E type 2x10 chainstay mount FD
Shift Levers
Jagwire LEX housing
Cassette
Shimano SLX HG-81
Crank
Shimano SLX 38/24 2 x 10
Bottom Bracket
N/A
Chain
Shimano HG-74
Chain Tensioner
Bionicon C-Guide
Pedals
N/A
Wheels
Front Hub
SLX 15 mm front hub center lock
Rear Hub
Shimano SLX 142 x 12
Rims
Mavic XM 119 disc trail rims
Tires
Continental X King 26 x 2.2 Folding bead
Brakes
Brakes
Shimano SLX
Brake Levers
Shimano 180 mm front rotor
Disk Rotors
N/A
Cockpit
Stem
Norco short reach 3D forged
Handlebar
Norco 6061 butted 740 mm width 25 mm rise
Grips
Ergon GA1 EVO
Headset
FSA #57 E ( tapered internal ) 1.5" to 1-1/8"
Seat
Saddle
WTB Volt Race with chromoly rail
Seatpost
X-Fusion Hilo series dropper seatpost 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | - | - | - | - | - |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.478 mm | 1.415 mm | 1.366 mm | 1.318 mm | 1.273 mm |
| Bottom Bracket Height | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm | 340.5 mm |
| Front Center | 657 mm | 683 mm | 709 mm | 736 mm | 762 mm |
| Rake | 43 mm | 42 mm | 42 mm | 43 mm | 42 mm |
| Trail | 96 mm | 97 mm | 97 mm | 96 mm | 97 mm |
| Stack | 560 mm | 569 mm | 579 mm | 588 mm | 597 mm |
| Reach | 379 mm | 402 mm | 424 mm | 446 mm | 469 mm |
| Top Tube Length | 540 mm | 565 mm | 590 mm | 615 mm | 640 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 405 mm | 435 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1082 mm | 1108 mm | 1134 mm | 1161 mm | 1187 mm |
| Front Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
About this model
Sight 2 completes the Norco Sight model. 215 bikes variations carry this model name so far. You can get a glimpse at all models from 2013, by clicking on this link.
Model range prices
Norco Sight 3 2013 is the most affordable bike of this model and has a price of 2350$. On the other hand, Norco Sight Killer B-1 2013, is the most expensive and costs 5135$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2013, its price was 3515$. In conclusion, this bike price is 27.26% higher than the price of the average Trail bike.
Sight 2 components
Fork
The fork installed on this bike is the RockShox Revelation RC model. The travel on this model is 140mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
As for the rear shock, this bike has the Fox Float CTD SV (No BV) – Evolution model, with a travel of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
As for the wheels, Norco Sight 2 2013, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Sight 2 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
