Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
137cm - 147cm
XS
146cm - 156cm
SM
154cm - 165cm
MD
163cm - 174cm
MD
165cm - 177cm
LG
172cm - 182cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCM HLO DS, 100mm Travel, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100
Shift Levers
Shimano Deore SL-M5100
Cassette
Shimano Deore CS-M5100, 11-51T, 11 Speed
Crank
Shimano Deore FC-M5100-1, 30T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Shimano Cartridge Bearing, BSA Threaded
Chain
KMC X11
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
Alex DP21 TRS
Tires
Maxxis Rekon DK60 2.25"
Brakes
Brakes
Tektro HD-M275 Hydraulic, Resin Pads
Brake Levers
Tektro HD-M275, HD-M276 Short Reach on Step-Thru
Disk Rotors
Tektro 160mm
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
VP Lock-On
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
TranzX YSP18 Dropper, 130mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.79 mm | 1.67 mm | 1.56 mm | 1.46 mm | 1.48 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 602 mm | 636 mm | 326 mm | 703 mm | 703 mm | 737 mm | 771 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm | 92 mm | 92 mm | 92 mm |
| Stack | 583 mm | 593 mm | 602 mm | 606 mm | 615 mm | 624 mm | 634 mm |
| Reach | 326 mm | 356 mm | 386 mm | 416 mm | 416 mm | 446 mm | 476 mm |
| Top Tube Length | 485 mm | 517 mm | 550 mm | 581 mm | 583 mm | 616 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 340 mm | 390 mm | 430 mm | 470 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1023 mm | 1057 mm | mm | 1125 mm | 1137 mm | 1171 mm | 1205 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 44 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 579 mm | 607 mm | 623 mm | 664 mm | 677 mm | 712 mm | 745 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 137 cm | 146 cm | 154 cm | 163 cm | 165 cm | 172 cm | 181 cm |
| Rider Max Height | 147 cm | 156 cm | 165 cm | 174 cm | 177 cm | 182 cm | 191 cm |
About this model
Storm 1 29 is a Norco Storm model. There are 177 bikes that carry this model name. You can easily view all of the Norco Storm bikes models from 2021, here.
Model range prices
Norco Storm 2.3 2021 is the most economical model, with a starting price of 479$. Norco Storm 1 27.5 2021 on the other hand costs 1149$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Storm 1 29 price was 1149$. In conclusion, this bike price is 65.8% lower than the price of the average Crosscountry bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
The fork installed on this bike is the SunTour XCM HLO model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the Storm 1 29 bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Storm 1 29 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Storm 1 29 comes in 7 sizes, that range from 137 cm – 191 cm (4.49 ft – 6.27 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Norco model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
