Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCM HLO
-
Groupset Deore -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XXS
137cm - 147cm
XS
146cm - 156cm
SM
154cm - 165cm
MD
163cm - 174cm
MD
174cm - 183cm
LG
172cm - 182cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, Internal Routing, Smooth Welds
Suspension Fork
Suntour XCM HLO DS, 100mm Travel, 42mm Offset (27.5), 46mm Offset (29)
Drivetrain
Rear Derailleur
Shimano Deore RD-M5120
Shift Levers
Shimano Deore SL-M4100
Cassette
Shimano Deore CS-M4100, 11-46T, 10 Speed
Crank
Pro Wheel CY10Y-NW, 30T, 170mm (XXS, XS, S), 175mm (M, L, XL)
Bottom Bracket
Cartridge, BSA Threaded
Chain
KMC X10
Pedals
VP Nylon Flat
Wheels
Front Hub
Alloy QR, 9x100mm QR, 6 Bolt
Rear Hub
Alloy QR, 10x135mm QR, HG, 6 Bolt
Rims
Alex DP21 TRS
Tires
Maxxis Rekon DK60 2.25"
Brakes
Brakes
Tektro HD-M275 Hydraulic, Resin Pads
Brake Levers
Tektro HD-M275, HD-M276 Short Reach on Step-Thru
Disk Rotors
Tektro 160mm
Cockpit
Stem
Alloy 60mm, 31.8mm Clamp
Handlebar
X6 Alloy, 720mm (XXS, XS, S), 740mm (M, L, XL), 25mm Rise
Grips
VP Lock-On
Headset
Zero Stack
Seat
Saddle
Norco XC
Seatpost
Alloy 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.79 mm | 1.67 mm | 1.56 mm | 1.46 mm | 1.48 mm | 1.4 mm | 1.33 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 602 mm | 636 mm | 670 mm | 703 mm | 703 mm | 737 mm | 771 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 98 mm | 98 mm | 98 mm | 98 mm | 92 mm | 92 mm | 92 mm |
| Stack | 583 mm | 593 mm | 602 mm | 606 mm | 615 mm | 624 mm | 634 mm |
| Reach | 326 mm | 356 mm | 386 mm | 416 mm | 416 mm | 446 mm | 476 mm |
| Top Tube Length | 485 mm | 517 mm | 550 mm | 581 mm | 583 mm | 616 mm | 648 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 340 mm | 390 mm | 430 mm | 470 mm | 470 mm | 510 mm | 550 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1023 mm | 1057 mm | 1091 mm | 1125 mm | 1137 mm | 1171 mm | 1205 mm |
| Bottom Bracket Drop | 49 mm | 49 mm | 49 mm | 44 mm | 63 mm | 63 mm | 63 mm |
| Standover Height | 579 mm | 607 mm | 623 mm | 664 mm | 677 mm | 712 mm | 745 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 137 cm | 146 cm | 154 cm | 163 cm | 174 cm | 172 cm | 181 cm |
| Rider Max Height | 147 cm | 156 cm | 165 cm | 174 cm | 183 cm | 182 cm | 191 cm |
Model Overview
Storm 2 27.5 is part of the Norco Storm model. Norco released 177 bikes variations of this model so far. You can easily view all of the Norco Storm bikes models from 2021, here.
Model range prices
Norco Storm 2.3 2021 is the most economical model, with a starting price of 479$. Norco Storm 1 27.5 2021 on the other hand costs 1149$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Norco released this model in 2021, its price was 949$. In conclusion, this bike price is 100.74% lower than the price of the average Crosscountry bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Storm 2 27.5 components
Fork
The fork installed on this bike is the SunTour XCM HLO model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
The wheels on Storm 2 27.5 are the 27.5″ aluminum type. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Storm 2 27.5 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
Storm 2 27.5 comes in 7 sizes, that range from 137 cm – 191 cm (4.49 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
